Job No.: TCS00694/13 |
|
|
||
|
|
|
|
|
||
|
|
Agreement No. CE 45/2008
(CE) Liantang/ Heung Yuen Wai
Boundary Control Point
and Associated Works |
|
|
||
|
|
|
|
|
||
|
|
Monthly Environmental Monitoring and Audit Report
(No.67) ¡V February 2019 |
|
|
||
|
|
Prepared For |
|
|
||
|
|
Civil Engineering and Development Department (CEDD) |
|
|
||
Date |
Reference No. |
Prepared By |
Certified By |
14 March 2019 |
TCS00694/13/600/R1993v2 |
|
|
Nicola Hon (Environmental Consultant) |
Tam Tak Wing (Environmental Team Leader) |
Version |
Date |
Remarks |
1 |
8 March 2019 |
First Submission |
2 |
14 March 2019 |
Amended according to the
IEC¡¦s comments on 11 and 13 March 2019 |
|
|
|
executive summary
ES01
This is the 67th monthly EM&A
report presenting the monitoring results and inspection findings for the reporting period from 1 to 28 February 2019 (hereinafter ¡¥the
Reporting Period¡¦).
Environmental
Monitoring and Audit Activities
ES02
To facilitate the project management and
implementation, Liantang/Heung Yuen Wai
Boundary Control Point and Associated Works of the Project is
divided to seven CEDD contracts including Contract 2 (CV/2012/08), Contract 3 (CV/2012/09), Contract 4 (NE/2014/02), Contract 5 (CV/2013/03),
Contract 6 (CV/2013/08) and Contract 7 (NE/2014/03) and an ArshSD contract
(Contract SS C505).
ES03
In the Reporting Period, the major
construction works under Liantang/Heung
Yuen Wai Boundary Control Point and Associated Works of the Project
included Contract 2, Contract 3, Contract 4, Contract
6, Contract 7 and Contract SS C505.
Environmental monitoring activities under the EM&A programme in the
Reporting Period are summarized in the following table.
Environmental Aspect |
Environmental
Monitoring Parameters / Inspection |
Reporting Period |
|
Number of Monitoring
Locations to undertake |
Total Occasions |
||
Air Quality |
1-hour TSP |
9 |
150 |
24-hour TSP |
9 |
49 |
|
Construction Noise |
Leq(30min) Daytime |
10 |
45 |
Water Quality |
Water in-situ
measurement and/or sampling |
WM1 & WM1-C |
11 Scheduled & 0 extra |
WM2A(a) & WM2A-Cx |
11 Scheduled & 1 extra |
||
WM2B & WM2B-C |
11 Scheduled & 0 extra (*) |
||
WM3x &WM3-C |
11 Scheduled & 0 extra |
||
WM4, WM4-CA &WM4-CB |
11 Scheduled & 1 extra |
||
Ecology |
Woodland compensation i) General Health condition of planted species ii) Survival of planted species |
9 Quadrats and transect |
1 |
Joint Site Inspection / Audit |
IEC, ET, the Contractor and RE joint site
Environmental Inspection and Auditing |
Contract 2 |
4 |
Contract 3 |
4 |
||
Contract 4 |
5 |
||
Contract 6 |
4 |
||
Contract 7 |
5 |
||
Contract SS C505 (#) |
4 |
Remark: (#) IEC only joined one (1) event of site inspection for
Contract SS C505.
(*)
In whole Reporting Period, water sampling was unable to carry out at WM2B and WM2B-C due to shallow
water (water depth under 150mm)
Action and Limit (A/L) Levels exceedance
ES04
In the Reporting Period, no construction noise exceedance
and valid noise complaint was recorded. For air quality monitoring, no exceedance of 1-hour and 24-hour TSP was recorded. Furthermore, 4 Limit Level
exceedances were recorded during water quality monitoring. The summary of exceedance in the
Reporting Period is shown below.
Environmental
Aspect |
Monitoring Parameters |
Action Level |
Limit Level |
Event & Action |
|||
NOE Issued |
Investigation Result |
Project related exceedance |
Corrective Actions |
||||
Air Quality |
1-hour TSP |
0 |
0 |
0 |
-- |
-- |
-- |
24-hour TSP |
0 |
0 |
0 |
-- |
-- |
-- |
|
Construction Noise |
Leq(30min) Daytime |
0 |
0 |
0 |
-- |
-- |
-- |
Water Quality |
DO |
0 |
0 |
0 |
-- |
-- |
-- |
Turbidity |
0 |
2 |
2 |
Refer to ES.05 |
The Contractor should fully implement water quality mitigation
measure. |
||
SS |
0 |
2 |
2 |
ES05
A total of Four
(4) Limit Level
exceedances were recorded during water quality
monitoring. The investigation report for exceedance recorded at WM2A(a) on 8
February 2019 revealed that exceedance was not related to the work under the
project. The investigation report
for exceedance recorded at WM4 on 25 February 2019 is still underway by ET and
the investigation result will be presented in next Monthly EM&A Report.
Environmental
Complaint
ES06
In this Reporting
Period, two (2) documented environmental
complaints were received for Contract 3 regarding the construction
noise and site cleanliness issues. The
complaint details and status of investigation are summarized below.
(a) A public complaint was received by EPD on 28
January 2019 about noise disturbance generated by the construction works at 8pm
at Kau Lung Hang claiming from Chun Wo¡¦s construction site. The Contractor confirmed that there was
no construction activity after 18:00 on 28 January 2019. Investigation
was conducted by ET and the IR revealed that the complaint was not valid to
Contract 3.
(b) A public complaint was received by 1823 on 21 Feb
2019 about cleanliness of Chun Wo construction site near Yuen Leng concerning
on water spraying around the site area causing mud and muddy water rush out
from the site to public road. Investigation is underway by ET.
Notification
of Summons and Successful Prosecutions
ES07
No environmental
summons and prosecutions were recorded in the Reporting Period.
Reporting Change
ES08
No reporting
changes were made in the Reporting Period.
ES09
In this Reporting Period, joint site inspection to evaluate the site
environmental performance at Contract 2 has been carried out by
the RE, IEC, ET and the Contractor on 1, 8, 15 and 21
February 2019.
No non-compliance was noted during the site inspection.
ES10
In the Reporting Period, joint site
inspection to evaluate the site environmental performance at Contract
3 has been carried out by the RE, IEC, ET and the Contractor on 8, 14, 20 and 28 February 2019. No non-compliance was noted during the site
inspection.
ES11
In the Reporting Period, joint site
inspection to evaluate
the site environmental performance at Contract 4 has been
carried out by the RE, IEC, ET and
the Contractor on 1, 8, 15, 22 and
25 February 2019. No non-compliance was noted.
ES12
In the Reporting Period, joint site
inspection to evaluate the site environmental performance at Contract
6 has been carried out by the RE, IEC, ET and the Contractor on 8, 14, 21 and 28 February 2019. No non-compliance was noted during the site inspection.
ES13
In the Reporting Period, joint site
inspection for Contract 7 to
evaluate the site environmental performance has been carried out by the RE,
IEC, ET and the Contractor on 1, 8, 15, 22 and
26 February 2019. No non-compliance was noted during the site inspection.
ES14
In the Reporting Period, joint site
inspection to evaluate the site environmental performance at Contract
SS C505 has been carried out by the RE, ET and the Contractor on 4, 13, 20 and 27
February 2019 in which IEC joined the site inspection on 20
February 2019. No non-compliance was noted during the site inspection.
Future Key Issues
ES15
As wet season is approaching, preventive measures for
muddy water or other water pollutants from site surface flow to local stream
such as Kong Yiu Channel, Ma Wat Channel, Ping Yuen River, Kwan Tei River or
public area should be properly maintained.
The Contractors should paid special attention on water quality
mitigation measures and fully implement according ISEMM of the EM&A Manual.
ES16
In addition, all effluent
discharge shall be ensure to fulfill Technical Memorandum of Effluent
Discharged into Drainage and Sewerage Systems, inland and Coastal Waters
criteria or discharge permits stipulation.
ES17
Construction noise would be a key
environmental issue during construction work of the Project. Noise mitigation measures such as using
quiet plants should be implemented in accordance with the EM&A requirement.
ES18
Since most of construction sites under the
Project are located adjacent to villages, the Contractors should fully
implement air quality mitigation measures to reduce construction dust emission.
Table of Contents
2 Project
Organization and Construction progress
2.1 Construction
Contract Packaging
2.5 Summary of Environmental Submissions
3 Summary of
Impact Monitoring Requirements
3.4 Monitoring
Frequency and Period
3.8 Derivation
of Action/Limit (A/L) Levels
3.9 Data
Management and Data QA/QC Control
4.2 Air
Quality Monitoring Results
5 Construction
Noise Monitoring
6.2 Results
of Water Quality Monitoring
8.2 Records
of Waste Quantities
9.2 Findings
/ Deficiencies During the Reporting Month
10 Environmental Complaint and
Non-Compliance
10.1 Environmental
Complaint, Summons and Prosecutions
11 Implementation Status of
Mitigation Measures
11.2 Tentative
Construction Activities in the Coming Month
11.3 Key
Issues for the Coming Month
12 Conclusions and
Recommendations
List
of TABLES
Table 2-1 Status
of Environmental Licenses and Permits of the Contracts
Table 3-1 Summary
of EM&A Requirements
Table 3-2 Impact
Monitoring Stations - Air Quality
Table 3-3 Impact
Monitoring Stations - Construction Noise
Table 3-4 Impact
Monitoring Stations - Water Quality
Table 3-5 Air
Quality Monitoring Equipment
Table 3-6 Construction
Noise Monitoring Equipment
Table 3-7 Water
Quality Monitoring Equipment
Table 3-8 Action
and Limit Levels for Air Quality Monitoring
Table 3-9 Action
and Limit Levels for Construction Noise
Table 3-10 Action and Limit
Levels for Water Quality
Table 4-1 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM1c
Table 4-2 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM2
Table 4-3 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM3
Table 4-4 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM4b
Table 4-5 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM5a
Table 4-6 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM6
Table 4-7 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM7b
Table 4-8 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM8
Table 4-9 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM9b
Table 5-1 Summary
of Construction Noise Monitoring Results
Table 5-2 Summary
of Construction Noise Monitoring Results
Table 6-1 Water
Quality Monitoring Results Associated of Contracts 2 and 3
Table 6-2 Water
Quality Monitoring Results Associated of Contracts 6 and SS C505
Table 6-3 Water
Quality Monitoring Results Associated only Contract 6
Table 6-4 Water
Quality Monitoring Results Associated Contracts 2 and 6
Table 6-5 Action
and Limit (A/L) Levels Exceedance Recorded
Table 6-6 Summary
of Water Quality Exceedance in the Reporting Period
Table 8-1 Summary
of Quantities of Inert C&D Materials for the Project
Table 8-2 Summary
of Quantities of C&D Wastes for the Project
Table 9-1 Site
Observations for Contract 2
Table 9-2 Site
Observations for Contract 3
Table 9-3 Site
Observations for Contract 4
Table 9-4 Site
Observations for Contract 6
Table 9-5 Site
Observations for Contract SS C505
Table 9-6 Site
Observations for Contract 7
Table 10-1 Statistical
Summary of Environmental Complaints
Table 10-2 Statistical
Summary of Environmental Summons
Table 10-3 Statistical
Summary of Environmental Prosecutions
Table 11-1 Environmental
Mitigation Measures
List of Appendices
Appendix
A Layout Plan of the
Project
Appendix
B Organization Chart
Appendix
C 3-month rolling
construction program
Appendix
D Designated
Monitoring Locations as Recommended in the Approved EM&A Manual
Appendix
E Monitoring
Locations for Impact Monitoring
Appendix
F Calibration
Certificate of Monitoring Equipment and HOKLAS-accreditation Certificate of the
Testing Laboratory
Appendix
G Event and Action
Plan
Appendix
H Impact Monitoring
Schedule
Appendix
I Database of
Monitoring Result
Appendix J Graphical Plots for
Monitoring Result
Appendix
K Meteorological
Data
Appendix
L Waste Flow Table
Appendix
M Implementation Schedule
for Environmental Mitigation Measures
Appendix
N Investigation
Report for Exceedance
Appendix O Investigation
Report for Complaint
1.1.1
Civil Engineering and Development Department is the Project Proponent and the Permit Holder of Agreement No. CE 45/2008 (CE)
Liantang / Heung Yuen Wai Boundary Control Point and Associated Works,
which is a Designated Project to be implemented under Environmental Permit
number EP-404/2011/D granted on 20 January 2017.
1.1.2
The Project consists of two main components: Construction of a Boundary
Control Point (hereinafter referred as ¡§BCP¡¨); and Construction of a connecting
road alignment. Layout plan of the Project is shown in Appendix A.
1.1.3
The proposed BCP is located at the boundary with Shenzhen near the
existing Chuk Yuen Village, comprising a main passenger building with passenger
and cargo processing facilities and the associated customs, transport and
ancillary facilities. The
connecting road alignment consists of six main sections:
1)
Lin Ma Hang to Frontier Closed Area (FCA) Boundary ¡V this section
comprises at-grade and viaducts and includes the improvement works at Lin Ma
Hang Road;
2)
Ping Yeung to Wo Keng Shan ¡V this section stretches from the Frontier
Closed Area Boundary to the tunnel portal at Cheung Shan and comprises at-grade
and viaducts including an interchange at Ping Yeung;
3)
North Tunnel ¡V this section comprises the tunnel segment at Cheung Shan
and includes a ventilation building at the portals on either end of the tunnel;
4)
Sha Tau Kok Road ¡V this section stretches from the tunnel portal at Wo
Keng Shan to the tunnel portal south of Loi Tung and comprises at-grade and
viaducts including an interchange at Sha Tau Kok and an administration
building;
5)
South Tunnel ¡V this section comprises a tunnel segment that stretches from
Loi Tung to Fanling and includes a ventilation building at the portals on
either end of the tunnel as well as a ventilation building in the middle of the
tunnel near Lau Shui Heung;
6)
Fanling ¡V this section comprises the at-grade, viaducts and interchange
connection to the existing Fanling Highway.
1.1.4
Action-United
Environmental Services & Consulting has
been commissioned as an Independent ET to implement the relevant
EM&A program in accordance with the
approved EM&A Manual, as well as the associated duties. As part of the EM&A program,
the baseline monitoring has carried out between 13 June 2013 and 12 July
2013 for all parameters including air quality, noise and water quality
before construction work commencement.
The Baseline Monitoring Report summarized the key findings and the
rationale behind determining a set of Action and Limit Levels (A/L Levels) from
the baseline data. Also, the
Project baseline monitoring report which verified by the IEC has been submitted
to EPD on 16 July 2013 for
endorsement. The major construction
works of the Project was commenced on 16
August 2013 in accordance with the EP Section 5.3 stipulation.
1.1.5
This is 67th monthly EM&A report
presenting the monitoring results and inspection findings for reporting period from 1 to 28 February 2019.
1.2.1
The Monthly Environmental Monitoring and
Audit (EM&A) Report is structured into the following sections:-
Section 1 Introduction
Section 2 Project Organization and Construction
Progress
Section 3 Summary
of Impact Monitoring Requirements
Section 4 Air Quality Monitoring
Section 5 Construction Noise Monitoring
Section 6 Water Quality Monitoring
Section 7 Ecology Monitoring
Section 8 Waste Management
Section 9 Site Inspections
Section 10 Environmental
Complaints and Non-Compliance
Section 11 Implementation
Status of Mitigation Measures
Section 12 Conclusions
and Recommendations
2.1.1
To facilitate the project management and
implementation, the Project would be divided by the following contracts:
¡P
Contract 2 (CV/2012/08)
¡P
Contract 3 (CV/2012/09)
¡P
Contract 4 (NE/2014/02)
¡P
Contract 5 (CV/2013/03)
¡P
Contract 6 (CV/2013/08)
¡P
Contract 7 (NE/2014/03)
¡P
ArchSD Contract No. SS C505
2.1.2
The
details of each contracts is summarized below and the delineation of each contracts is shown in Appendix A.
Contract 2 (CV/2012/08)
2.1.3
Contract 2 has awarded in December 2013 and construction
work was commenced on 19 May 2014.
Major Scope of Work of the Contract 2 is listed below:
¡P
construction of
an approximately 5.2km long dual two-lane connecting road (with about 0.4km of
at-grade road and 4.8km of tunnel) connecting the Fanling Interchange with the
proposed Sha Tau Kok Interchange;
¡P
construction of a
ventilation adit tunnel and the mid-ventilation building;
¡P
construction of
the north and south portal buildings of the Lung Shan Tunnel and their
associated slope works;
¡P
provision and
installation of ventilation system, E&M works and building services works
for Lung Shan tunnel and Cheung Shan tunnel and their portal buildings;
¡P
construction of
Tunnel Administration Building adjacent to Wo Keng Shan Road and the associated
E&M and building services works; and
¡P
construction of
associated footpath, slopes, retaining structures, drainage, sewerage,
waterworks, landscaping works and other ancillary works.
Contract 3 (CV/2012/09)
2.1.4
Contract 3 was awarded in July 2013 and
construction work was commenced on 5 November 2013. Major Scope of Work of the Contract 3 is
listed below:
¡P
construction of
four link roads connecting the existing Fanling Highway and the south portal of
the Lung Shan Tunnel;
¡P
realignment of
the existing Tai Wo Service Road West and Tai Wo Service Road East;
¡P
widening of the
existing Fanling Highway (HyD¡¦s entrustment works);
¡P
demolishing
existing Kiu Tau vehicular bridge and Kiu Tau footbridge and reconstruction of
the existing Kiu Tau Footbridge (HyD¡¦s entrustment works); and
¡P
construction of
associated footpath, slopes, retaining structures, drainage, sewerage,
waterworks, landscaping works and other ancillary works.
Contract 4 (NE/2014/02)
2.1.5
Contract
4 has awarded in mid-April 2016 and
construction work was commenced
on 2 May 2017. The scope of work of the Contract 4
includes:
¡P
design, supply,
delivery, installation, testing and commissioning of a traffic control and
surveillance system for the connecting road linking up the Liantang / Heung
Yuen Wai Boundary Control Point and the existing Fanling Highway.
Contract 5 (CV/2013/03)
2.1.6
Contract 5 has awarded in April 2013 and
construction work was commenced in August 2013. Major Scope of Work of the Contract 5 is
listed below:
¡P
site formation of about 23
hectares of land for the development of the BCP;
¡P
construction of an
approximately 1.6 km long perimeter road at the BCP including a 175m long
depressed road;
¡P
associated
diversion/modification works at existing local roads and junctions including
Lin Ma Hang Road;
¡P
construction of pedestrian
subway linking the BCP to Lin Ma Hang Road;
¡P
provision of resite area with
supporting infrastructure for reprovisioning of the affected village houses;
and
¡P
construction of associated
footpath, slopes, retaining structures, drainage, sewerage, waterworks,
landscaping works and other ancillary works.
Contract 6 (CV/2013/08)
2.1.7
Contract 6 has awarded in June 2015 and
construction work was commenced on 23 October 2015. Major Scope of Work of the Contract 6
would be included below:
construction of an
approximately 4.6km long dual two-lane connecting road (with about 0.6km of
at-grade road, 3.3km of viaduct and 0.7km of tunnel) connecting the BCP with
the proposed Sha Tau Kok Road Interchange and the associated ventilation
buildings;
associated
diversion/modification works at access roads to the resite of Chuk Yuen
Village;
provision of sewage
collection, treatment and disposal facilities for the BCP and the resite of
Chuk Yuen Village;
construction of a pedestrian
subway linking the BCP to Lin Ma Hang Road;
provisioning of the affected
facilities including Wo Keng Shan Road garden; and
construction of
associated footpath, slopes, retaining structures, drainage, sewerage,
waterworks, landscaping works and other ancillary works.
Contract 7 (NE/2014/03)
2.1.8
Contract 7 has awarded in December 2015 and
the construction works of Contract 7 was commenced on 15 February 2016. Major Scope of Work of the Contract 7
would be included below:
construction of the Hong Kong Special
Administrative Region (HKSAR) portion of four vehicular bridge
construction of one pedestrian bridge crossing Shenzhen (SZ) River
(cross boundary bridges)
ArchSD Contract No. SS
C505
2.1.9
SS C505 has awarded in July 2015 and
construction work was commenced on 1 September 2015. Major Scope of Work of the SS C505 would
be included below:
passenger-related facilities including
processing kiosks and examination facilities for private cars and coaches,
passenger clearance building and halls, the interior fitting works for the
pedestrian bridge crossing Shenzhen River, etc.;
cargo processing facilities including kiosks
for clearance of goods vehicles, customs inspection platforms, X-ray building,
etc.;
accommodation for the facilities inside of the
Government departments providing services in connection with the BCP;
transport-related facilities inside the BCP
including road networks, public transport interchange, transport drop-off and
pick-up areas, vehicle holding areas and associated road furniture etc;
a public carpark; and
other ancillary facilities such as sewerage
and drainage, building services provisions and electronic systems, associated
environmental mitigation measure and landscape works.
2.2.1
The project organization is shown in Appendix B. The responsibilities
of respective parties are:
Civil
Engineering and Development Department (CEDD)
2.2.2
CEDD is the Project Proponent and the Permit Holder of the EP of the development
of the Project and will assume overall responsibility for the project. An
Independent Environmental Checker (IEC) shall be employed by CEDD to audit the
results of the EM&A works carried out by the ET.
Architectural
Services Department (ArchSD)
2.2.3
ArchSD acts as the works agent for
Development Bureau (DEVB), for Contract SS C505 Liantang/ Heung Yuen Wai
Boundary Control Point (BCP) ¡V BCP Buildings and Associated Facilities.
Environmental
Protection Department (EPD)
2.2.4
EPD is the statutory enforcement body for
environmental protection matters in Hong Kong.
Ronald Lu
& Partners (Hong Kong) Ltd (The Architect)
2.2.5
Ronald Lu & Partners (Hong Kong) Ltd is
appointed by ArchSD as an Architect for Contract SS C505 Liantang/ Heung Yuen
Wai Boundary Control Point (BCP) ¡V BCP Buildings and Associated
Facilities. It responsible for
overseeing the construction works of Contract SS C505 and for ensuring that the
works are undertaken by the Contractor in accordance with the specification and
contract requirements. The duties and responsibilities of the Architect with
respect to EM&A are:
Monitor the Contractors¡¦ compliance with
contract specifications, including the implementation and operation of the
environmental mitigation measures and their effectiveness
Monitor Contractors¡¦ and ET¡¦s compliance with
the requirements in the Environmental Permit (EP) and EM&A Manual
Facilitate ET¡¦s implementation of the EM&A
programme
Participate in joint site inspection by the ET
and IEC
Oversee the implementation of the agreed Event
/ Action Plan in the event of any exceedance
Adhere to the procedures for carrying out complaint
investigation
Liaison with DSD, Engineer/Engineer¡¦s
Representative, ET, IEC and the Contractor of the ¡§Construction of the DSD¡¦s
Regulation of Shenzhen River Stage 4 (RSR 4)¡¨ Project discussing regarding the
cumulative impact issues.
Engineer or
Engineers Representative (ER)
2.2.6
The ER is responsible for overseeing the
construction works and for ensuring that the works are undertaken by the
Contractor in accordance with the specification and contract requirements. The
duties and responsibilities of the ER with respect to EM&A are:
¡P
Monitor the Contractors¡¦ compliance with
contract specifications, including the implementation and operation of the
environmental mitigation measures and their effectiveness
¡P
Monitor Contractors¡¦s, ET¡¦s and IEC¡¦s
compliance with the requirements in the Environmental Permit (EP) and EM&A
Manual
¡P
Facilitate ET¡¦s implementation of the
EM&A programme
¡P
Participate in joint site inspection by the
ET and IEC
¡P
Oversee the implementation of the agreed
Event / Action Plan in the event of any exceedance
¡P
Adhere to the procedures for carrying out
complaint investigation
¡P
Liaison with DSD, Engineer/Engineer¡¦s
Representative, ET, IEC and the Contractor of the ¡§Construction of the DSD¡¦s
Regulaiton of Shenzhen River Stage 4 (RSR 4)¡¨ Project discussing regarding the
cumulative impact issues.
The
Contractor(s)
2.2.7
There will be one contractor for each
individual works contract. Once the contractors are appointed, EPD, ET and IEC
will be notified the details of the contractor.
2.2.8
The Contractor for Contracts under CEDD
should report to the ER. For ArchSD Contract, the Contractor should report to
the Architect or Architect¡¦s Representative (AR). The duties and
responsibilities of the Contractor are:
¡P
Comply with the relevant contract conditions
and specifications on environmental protection
¡P
Employ an Environmental Team (ET) to
undertake monitoring, laboratory analysis and reporting of EM &A Facilitate
ET¡¦s monitoring and site inspection activities
¡P
Participate in the site inspections by the ET
and IEC, and undertake any corrective actions
¡P
Provide information / advice to the ET
regarding works programme and activities which may contribute to the generation
of adverse environmental impacts
¡P
Submit proposals on mitigation measures in
case of exceedances of Action and Limit levels in accordance with the Event /
Action Plans
¡P
Implement measures to reduce impact where
Action and Limit levels are exceeded
¡P
Adhere to the procedures for carrying out
complaint investigation
Environmental Team (ET)
2.2.9
Once the ET is appointed, the EPD, CEDD, ER,
Architect and IEC will be notified the details of the ET.
2.2.10
The ET shall not be in any way an associated
body of the Contractor(s), and shall be employed by the Project
Proponent/Contractor to conduct the EM&A programme. The ET should be managed by the ET
Leader. The ET Leader shall be a person who has at least 7 years¡¦ experience in
EM&A and has relevant professional qualifications. Suitably qualified staff
should be included in the ET, and resources for the implementation of the
EM&A programme should be allocated in time under the Contract(s), to enable
fulfillment of the Project¡¦s EM&A requirements as specified in the EM&A
Manual during construction of the Project.
The ET shall report to the Project Proponent and the duties shall
include:
¡P
Monitor and audit various environmental
parameters as required in this EM&A Manual
¡P
Analyse the environmental monitoring and
audit data, review the success of EM&A programme and the adequacy of
mitigation measures implemented, confirm the validity of the EIA predictions
and identify any adverse environmental impacts arising
¡P
Carry out regular site inspection to
investigate and audit the Contractors¡¦ site practice, equipment/plant and work
methodologies with respect to pollution control and environmental mitigation,
and effect proactive action to pre-empt problems
¡P
Monitor compliance with conditions in the EP,
environmental protection, pollution prevention and control regulations and
contract specifications
¡P
Audit environmental conditions on site
¡P
Report on the environmental monitoring and
audit results to EPD, the ER, the Architect, the lEC and Contractor or their
delegated representatives
¡P
Recommend suitable mitigation measures to the
Contractor in the case of exceedance of Action and Limit levels in accordance
with the Event and Action Plans
¡P
Liaise with the IEC on all environmental
performance matters and timely submit all relevant EM&A proforma for
approval by IEC
¡P
Advise the Contractor(s) on environmental improvement,
awareness, enhancement measures etc., on site
¡P
Adhere to the procedures for carrying out
complaint investigation
¡P
Liaison with the client departments,
Engineer/Engineer¡¦s Representative, ET, lEC and the Contractor(s) of the
concurrent projects as listed under Section 2.3 below regarding the cumulative
impact issues.
Independent Environmental Checker (IEC)
2.2.11
One IEC will be employed for this Project.
Once the IEC is appointed, EPD, ER, the Architect and ET will be notified the
details of the IEC.
2.2.12
The Independent Environmental Checker (IEC)
should not be in any way an associated body of the Contractor or the ET for the
Project. The IEC should be employed by the Permit Holder (i.e., CEDD) prior to
the commencement of the construction of the Project. The IEC should have at
least 10 years¡¦ experience in EM&A and have relevant professional
qualifications. The appointment of IEC should be subject to the approval of
EPD. The IEC should:
¡P
Provide proactive advice to the ER and the
Project Proponent on EM&A matters related to the project, independent from
the management of construction works, but empowered to audit the environmental
performance of construction
¡P
Review and audit all aspects of the EM&A
programme implemented by the ET
¡P
Review and verify the monitoring data and all
submissions in connection with the EP and EM&A Manual submitted by the ET
¡P
Arrange and conduct regular, at least monthly
site inspections of the works during construction phase, and ad hoc inspections
if significant environmental problems are identified
¡P
Check compliance with the agreed Event /
Action Plan in the event of any exceedance
¡P
Check compliance with the procedures for
carrying out complaint investigation
¡P
Check the effectiveness of corrective
measures
¡P
Feedback audit results to ET by signing off
relevant EM&A proforma
¡P
Check that the mitigation measures are
effectively implemented
¡P
Verify the log-book(s) mentioned in Condition
2.2 of the EP, notify the Director by fax, within one working day of receipt of
notification from the ET Leader of each and every occurrence, change of
circumstances or non-compliance with the EIA Report and/or the EP, which might
affect the monitoring or control of adverse environmental impacts from the
Project
¡P
Report the works conducted, the findings,
recommendation and improvement of the site inspections, after reviewing ET¡¦s
and Contractor¡¦s works, and advices to the ER and Project Proponent on a
monthly basis
¡P
Liaison with the client departments,
Engineer/Engineer¡¦s Representative, the Architect, ET, lEC and the Contractor
of the concurrent projects as listed under Section 2.3 below regarding the
cumulative impact issues.
2.3.1
The concurrent construction works that may be
carried out include, but not limited to, the following:
(a)
Regulation of Shenzhen River Stage IV;
(b)
Widening of Fanling Highway ¡V Tai Hang to Wo
Hop Shek Interchange ¡V Contract No. HY/2012/06;
(c)
Construction of BCP
facilities in Shenzhen.
2.4.1
In the Reporting Period, the major
construction activity conducted under the Project is located in Contracts 2, 3,
6, 7 and SS C505 and they are summarized in below. Moreover, 3-month rolling construction
program for all the current contracts is enclosed in Appendix C.
Contract 2 (CV/2012/08)
2.4.2
The
contract commenced in May 2014. In this Reporting Period, construction
activities conducted are listed below:
Mid-Vent Portal |
Defect
rectification for the Mid-Ventilation Building
T&C for E&M facilities
Construction of flexible barrier and permanent
drainage
External reinstatement works and soft landscaping
works |
North Portal |
Defect rectification for the North Ventilation
Building
Construction of permanent drainage and slip road
Cladding installation, road paving and T&C
for E&M facilities
External backfilling and reinstatement works
Soft landscaping works |
South Portal |
Defect
rectification for the South Ventilation Building
Construction
of flexible barrier, permanent drainage and slip road
Cladding
installation, road paving and T&C for E&M facilities
External
backfilling and reinstatement works
Soft
landscaping works
Dismantling
the concrete pier for the temporary steel bridge |
Admin Building |
Defect
rectification for the Admin Build.
T&C for E&M facilities
External reinstatement and soft landscaping works |
Contract 3 (CV/2012/09)
2.4.3
The Contract commenced in November 2013. In this Reporting Period, construction
activities conducted are listed below:
Cable detection
and trial trenches
Remaining works
on new Footbridge
Noise barrier
construction
Road pavement
works
Water main
laying works (on Grade and on bridge deck)
Installation of
Noise barrier steel column & panel, and sign gantry (on Grade and on bridge
deck)
Road Drainage
Works
Waterproofing
works on bridge deck
Bitumen paving
on bridge deck
Construction of
Pavilion and Pai Lau
Construction of
retaining wall
Landscaping
works
Contract 4 (NE/2014/02)
2.4.4
The
Contract was awarded in mid-April 2016 and the construction work was commenced on 2 May 2017. In this Reporting Period, construction
activities conducted are listed below:
T&C at Admin
Building
T&C at
tunnel
Panel
installation at Cheung Shan Tunnel
Contract 5 (CV/2013/03)
2.4.5
The
construction works under Contract 5 was substantially completed on 31 August
2016.
Contract 6 (CV/2013/08)
2.4.6
Contract 6 has awarded in June 2015 and
construction work was commenced on 23 October 2015. In this Reporting Period,
construction activities conducted are listed below:
Bridge
construction
Tunneling
Works
Sewage
Treatment Plant Construction
Tunnel
Ventilation Building Construction
Slip
Road/At-grade Road/Periphery Road Construction
Contract 7 (NE/2014/03)
2.4.7
Contract 7 has awarded in December 2015 and construction
work was commenced on 15 February 2016.
In this Reporting Period, construction activities conducted are listed
below:
Noise barrier construction at Bridge D &E
Parapet installation at Bridge A & E
Waterproofing and Drainage works at roof of Bridge
C
Drainage and watermains at perimeter road
Bitumen pavement at Bridge A & E
Street lighting and CCTV installation at perimeter
road
Shenzhen River Reinstatement
Contract SS C505
2.4.8
Contract SS C505 has awarded in July 2015 and
construction work was commenced on 1 September 2015. In this Reporting Period, construction
activities conducted are listed below:
Passenger Terminal Building (PTB) Structure Works -
G/F Plant Rooms Structure Works, G/F Backfiling & Drainage, Under Ground
Utilities, Fence Wall and On Grade Slab
PTB - ABWF Works & MEP Installation -
Front/Back of House Area, External Staircases, External Staircases, Hall Block
External Façade, Southern Entrance Construction, Major Plant Rooms & EAC
Doors
PTB - External Works incl. Building 21-24, M/F
External Wall (Ewall), Roof & Upper Roof Roofing Works, Podium Coach
Canopy, 21&22 (C&PC KIOSKS) & 23&24 (PC Examination Building
& MXRVSS), Podium Open Area & Ambulance Canopy / Glazed Canopy
Bridge C Integrated ABWF and MEP Installation Works
(C7 Portion) - Arrival & Departure Hall, Staircases, Test &
Commissioning
Bldg 1 - C&ED Detector Dog Base Phase 1 -
Integrated ABWF & MEP Works at G/F, R/F & External
Bldg 2 - HKPF Building and Observation Tower Phase
1 - External Works, Integrated ABWF & MEP Works at G/F to 4/F, Observation
Tower (incluidng Lift) & External Works
Bldg 3 - Fire Station and Drill Tower Phase 1 -
External Works, Integrated ABWF & MEP Works at G/F to UR/F & Drill
Tower
Bldg 4 - Cargo Examination Building (Inbound) Phase
1 - External Works at G/F under Steel Roof, Integrated ABWF & MEP Works at
G/F to R/F & Loading Dock
Bldg 5 - Cargo Examination Building (Outbound)
Phase 2 - External Works at G/F under Steel Roof, Integrated ABWF & MEP
Works at G/F to R/F & Loading Dock
Bldg 6 - Fixed X-ray Vehicle Inspection System
(FXRVIS) Buildings (Inbound) Phase 1 - External Works (FXI Fence Wall),
Integrated ABWF & MEP Works at G/F to R/F
Bldg 7 - Fixed X-ray Vehicle Inspection System
(FXRVIS) Buildings (Outbound) Phase 2 - External Works, Integrated ABWF &
MEP Works at G/F to 1/F & Roof works
Bldg 8 - MXRVSS (Inbound) Phase 2 - Integrated ABWF
and MEP Works at G/F & R/F
Bldg 9 - MXRVSS (Outbound) Phase 2 - Structure
Works at G/F, Integrated ABWF and MEP Works at G/F & Envelope
Bldg 10 - GV Kiosk (Inbound) Phase 2 - On-Grade
Slab, Integrated ABWF and MEP Works at G/F & R/F
Bldg 11 - GV Kiosk (Outbound) Phase 2 - On-Grade
Slab, Integrated ABWF & MEP Works at G/F & R/F
Bldg 12 - Public Toilets (Inbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 13 - Public Toilets (Outbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & R/F
Bldg 14 - Disinsection Facilities (Inbound) Phase 2
- Integrated ABWF & MEP Works at G/F & Envelope
Bldg 15 - Disinsection Facilities (Outbound) Phase
2 - Substructure Works, Integrated ABWF & MEP Works at G/F & Envelope
Bldg 16 - Weigh Station Phase 2 - Integrated ABWF
and MEP Works at G/F & Envelope
Bldg 17 - EUVSS & Monitoring Room Phase 2 -
Structure Works, Integrated ABWF & MEP Works at G/F & R/F
Bldg 18 - Refuse Collection Point Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 25 - Traffic Control Office (Inbound) Phase 2
- Integrated ABWF and MEP Works at G/F & Envelope
Bldg 26 - Traffic Control Office (Outbound) Phase 2
- Integrated ABWF and MEP Works at G/F & Envelope
Bldg 27 - Inspection Post Phase 2 - Integrated ABWF
and MEP Work at G/F & Envelope
Bldg 28 - Guard Booth (Inbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 29 - Guard Booths (Vehicle Detention Area)
Phase 2 - Integrated ABWF and MEP Works at G/F & Envelope
Bldg 30 - Guard Booth (Outbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 31 - Guard Booth (Inbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 32/33/34/35 - Steel Canopy 1 to 4 Phase 2 -
Integrated ABWF and MEP Works
Bldg 36 - Fire Hydrant Tank & Pump Room Phase 1
- Integrated ABWF and MEP Works at R/F
Bldg 37/38/39 - Elevated Walkways (E1, E2 & E3)
Phase 2 - Structures Works, ABWF and BS Works
Bldg 40 - Elevated Walkway E4 Phase 2 - Structures
Works, ABWF and BS Works
Vehicular Bridges 1 & 4 Phase 3 - Retaining
walls, Road and Finishes Works
Vehicular Bridges 2, 3 & 5 Phase 3 - Road and
Finishes Works
External Works - Water Meter Room Connection
(inbound & outbound)
External Utilities Works - UU works for phase 2 FS
inspection & DSD inspection
External Road & Pavement Works - for inbound -
Phase 1 FS inspection & for Phase 2 FS inspection
External Landscape - Inbound & Outbound area
"Testing & Commissioning (T&C) and
FSD/SCCU Inspection Phase 1
T&C - FSD, HKPF, CBI, FXI, DOG & Bldg 36
FS Inspection
- FSD Cert. Issue & Final O&M Manual, Test Report
SCCU Inspection & Handover "
"Testing & Commissioning (T&C) and
FSD/SCCU Inspection Phase 2
T&C - CBO, FXO, Inbound & Outbound Groups
FS Inspection
- EVA, CBO & FXO, Inbound & Outbound Groups"
"Testing & Commissioning (T&C) and
FSD/SCCU Inspection Phase 3
T&C - EVA & PTB"
2.5.1
In according to the EP, the required
documents have submitted to EPD which listed in below:
Project Layout Plans of Contracts 2, 3, 4, 5,
6, 7 and SS C505
Landscape Plan
Topsoil Management Plan
Environmental Monitoring and Audit Programme
Baseline Monitoring Report
(TCS00690/13/600/R0030v3) for the Project
Waste Management Plan of the Contracts 2, 3,
4, 5, 6, 7 and SS C505
Contamination Assessment Plan (CAP) and
Contamination Assessment Report (CAR) for Po Kat Tsai, Loi Tung and the workshops
in Fanling
Vegetation Survey Report
Woodland Compensation Plan
Habitat Creation and Management Plan
Wetland Compensation Plan
2.5.2
Summary of
the relevant permits, licenses, and/or notifications on environmental protection
for the Project of each contracts are presented in Table 2-1.
Table 2-1 Status of Environmental
Licenses and Permits of the Contracts
Item |
Description |
License/Permit Status |
|||||
Ref. no. |
Effective Date |
Expiry Date |
|||||
Contract 2 |
|||||||
1 |
Air pollution Control (Construction Dust) Regulation |
Ref No.: 368864 |
31 Dec 2013 |
Till Contract ends |
|||
2 |
Chemical Waste Producer Registration |
North Portal Waste
Producers Number: No.5213-652-D2523-01 |
25 Mar 2014 |
Till Contract ends |
|||
Mid-Vent Portal Waste
Producers Number: No.5213-634-D2524-01 |
25 Mar 2014 |
Till Contract ends |
|||||
South Portal Waste
Producers Number: No.5213-634-D2526-01 |
9 Apr 2014 |
Till Contract ends |
|||||
3 |
Water Pollution Control Ordinance - Discharge License |
No.WT00018374-2014 (South Portal) |
3 Mar 2014 |
28 Feb
2019 |
|||
No. WT00023063-2015 (North Portal) |
18 Dec 2015 |
31 Mar 2019 |
|||||
No.: W5/1I392 (Admin Building) |
28 Mar 2014 |
31 Mar 2019 |
|||||
No.: WT00025594-2016 (Mid-Vent Portal) |
7 Oct 2016 |
31 Mar 2019 |
|||||
4 |
Waste Disposal Regulation - Billing Account for
Disposal of Construction Waste |
Account No. 7019105 |
8 Jan 2014 |
Till Contract ends |
|||
5 |
Construction Noise Permit |
GW-RN0063-19 |
North Portal |
31-Jan-2019 |
31-May-2019 |
||
GW-RN0065-19 |
31-Jan-2019 |
31-May-2019 |
|||||
GW-RN0084-19 |
11-Feb-2019 |
31-May-2019 |
|||||
GW-RN0400-18 |
Mid Vent |
06-Aug-2018 |
01-Feb-2019 |
||||
GW-RN0099-19 |
13-Feb-2019 |
31-May-2019 |
|||||
GW-RN0098-19 |
13-Feb-2019 |
31-May-2019 |
|||||
GW-RN0111-19 |
South Portal |
20-Feb-2019 |
1-Mar-2019 |
||||
GW-RN0511-18 |
30-Sep-2018 |
25-Mar-2019 |
|||||
GW-RN0513-18 |
30-Sep-2018 |
25-Mar-2019 |
|||||
GW-RN0523-18 |
Admin Bldg |
28-Sep-2018 |
27-Mar-2019 |
||||
GW-RN0522-18 |
Cheung Shan Tunnel |
26-Sep-2018 |
22-Mar-2019 |
||||
6 |
Specified Process License (Mortar
Plant Operation) |
L-3-251(1) |
12 Apr 2016 |
11 Apr 2021 |
|||
Contract 3 |
|||||||
1 |
Air pollution Control (Construction Dust) Regulation |
Ref. No: 362101 |
17 Jul 2013 |
Till Contract ends |
|||
2 |
Chemical Waste Producer Registration |
Waste Producers Number:
No.:5113-634-C3817-01 |
7 Oct 2013 |
Till Contract ends |
|||
3 |
Water Pollution Control Ordinance - Discharge License |
No.:WT00032188 ¡V 2018 |
20 Sep 2018 |
31 Aug
2023 |
|||
4 |
Waste Disposal Regulation - Billing Account for
Disposal of Construction Waste |
Account No. 7017914 |
2 Aug 2013 |
Till Contract ends |
|||
5 |
Construction Noise
Permit |
GW-RN0388-18 |
25 Aug 2018 |
24 Feb 2019 |
|||
GW-RN0424-18 |
01 Sep 2018 |
21 Feb 2019 |
|||||
GW-RN0425-18 |
22 Aug 2018 |
21 Feb 2019 |
|||||
GW-RN0454-18 |
06 Sep 2018 |
05 Mar 2019 |
|||||
GW-RN0566-18 |
29 Oct 2018 |
04 Apr 2019 |
|||||
GW-RN0693-18 |
18 Dec 2018 |
25 May 2019 |
|||||
GW-RN0694-18 |
19 Dec 2018 |
25 May 2019 |
|||||
GW-RN0696-18 |
19 Dec 2018 |
25 May 2019 |
|||||
GW-RN0699-18 |
18 Dec 2018 |
25 May 2019 |
|||||
GW-RN0058-19 |
25 Feb 2019 |
24 Aug 2019 |
|||||
GW-RN0064-19 |
06 Mar 2019 |
05 Sep 2019 |
|||||
GW-RN0067-19 |
22 Feb 2019 |
21 Aug 2019 |
|||||
Contract 6 |
|||||||
1 |
Air pollution Control (Construction Dust) Regulation |
Ref. No: 390614 |
29 Jun 2015 |
Till the end of Contract |
|||
2 |
Chemical Waste Producer Registration |
Waste Producers Number No.: 5213-652-C3969-01 |
31 Aug 2015 |
Till the end of Contract |
|||
3 |
Waste Disposal Regulation - Billing Account for
Disposal of Construction Waste |
Account No. 7022707 |
9 Jul 2015 |
Till the end of Contract |
|||
4 |
Water Pollution Control Ordinance - Discharge License |
No.:WT00024574-2016 |
31 May
2016 |
31 May
2021 |
|||
No.:WT00024576-2016 |
31 May
2016 |
31 May
2021 |
|||||
No.:WT00024742-2016 |
14 June 2016 |
30 June 2021 |
|||||
No.:WT00024746-2016 |
14 June 2016 |
30 June 2021 |
|||||
5 |
Construction Noise
Permit |
GW-RW0481-18 |
14 Sep 2018 |
13 Mar 2019 |
|||
GW-RW0595-18 |
30 Oct 2018 |
28 Feb 2019 |
|||||
Contract SS C505 |
|||||||
1 |
Air pollution Control (Construction Dust) Regulation |
Ref. No: 390974 |
13 Jul 2015 |
Till the end of Contract |
|||
2 |
Chemical Waste Producer Registration |
Waste Producer No.: 5213-642-L1048-07 |
16 Sep 2015 |
Till the end of Contract |
|||
3 |
Water Pollution Control Ordinance - Discharge License |
No.: WT00024865-2016 |
8 Jul 2016 |
30 Nov 2020 |
|||
4 |
Waste Disposal Regulation - Billing Account for
Disposal of Construction Waste |
Account No. 7022831 |
23 Jul 2015 |
Till the end of Contract |
|||
5 |
Construction Noise
Permit |
GW-RN0529-18 |
5 Oct 2018 |
3 Apr 2019 |
|||
GW-RN0133-19 |
9 Mar 2019 |
8 May 2019 |
|||||
GW-RN0754-18 |
9 Jan 2019 |
8 Mar 2019 |
|||||
Contract
7 |
|||||||
1 |
Air pollution Control (Construction Dust) Regulation |
Ref. No: 397015 |
21 Dec 2015 |
Till the end of Contract |
|||
2 |
Chemical Waste Producer Registration |
Waste Producer No.: 5214-641-K3202-01 |
24 Mar 2016 |
Till the end of Contract |
|||
3 |
Water Pollution Control Ordinance - Discharge License |
No.: WT00024422-2016 |
10 May
2016 |
31 May
2021 |
|||
4 |
Waste Disposal Regulation - Billing Account for
Disposal of Construction Waste |
Account No. 7024129 |
21 Jan 2016 |
Till the end of Contract |
|||
Contract 4 |
|||||||
1 |
Air pollution Control (Construction Dust) Regulation |
Ref. No.
405353 |
22 July 2016 |
Till the end of Contract |
|||
2 |
Waste Disposal Regulation - Billing Account for
Disposal of Construction Waste |
Account No. 7024973 |
13 May 2016 |
Till the end of Contract |
|||
3 |
Construction Noise
Permit |
GW-RN0697-18 |
10 Dec 2018 |
31 Mar 2019 |
|||
3.1.1
The Environmental Monitoring and Audit
requirements are set out in the Approved EM&A manual. Environmental issues
such as air quality, construction noise and water quality were identified as
the key issues during the construction phase of the Project.
3.1.2
A summary of construction phase EM&A
requirements are presented in the
sub-sections below.
3.2.1
The EM&A program of construction phase
monitoring shall cover the following environmental issues:
•
Air quality;
•
Construction noise; and
•
Water quality
3.2.2
A summary of the monitoring parameters is
presented in Table 3-1.
Table 3-1 Summary
of EM&A Requirements
Environmental Issue |
Parameters |
Air Quality |
1-hour
TSP by Real-Time Portable Dust Meter; and 24-hour TSP
by High Volume Air Sampler. |
Noise |
Leq(30min)
in normal working days (Monday to Saturday) 07:00-19:00 except public
holiday; and 3 sets
of consecutive Leq(5min) on restricted hours i.e. 19:00 to 07:00
next day, and whole day of public holiday or Sunday Supplementary
information for data auditing, statistical results such as L10 and
L90 shall also be obtained for reference. |
Water Quality |
In-situ Measurements Dissolved
Oxygen Concentration (mg/L); Dissolved
Oxygen Saturation (% ); Turbidity
(NTU); pH unit; Water
depth (m); and Temperature
(¢J). |
Laboratory Analysis
Suspended
Solids (mg/L) |
3.3.1
The designated monitoring locations as
recommended in the EM&A Manual
are shown in Appendix D. As the access to some of the designated
monitoring locations was questionable due to safety reason or denied by the
landlords, alternative locations therefore have had proposed. The latest alternative monitoring locations has been updated in the revised EM&A Programme (Rev.7) which approved by EPD on 7 April 2017. Besides, in view of Location AM1b was demolished
and returned to the landlord on 27 April
2018, alterative location AM1c was proposed by ET and approved by EPD on 26 November 2018. Table 3-2, Table 3-3 and Table 3-4
listed the air quality, construction noise and water quality monitoring
locations for the Project and a map showing these monitoring stations is
presented in Appendix E.
Table 3-2 Impact
Monitoring Stations - Air Quality
Station ID |
Description |
Works Area |
Related to the Work Contract |
AM1c
(*) |
Open area of Tsung Yuen Ha
Village No. 63 |
BCP |
SS C505 Contract 7 |
AM2 |
Village House
near Lin Ma Hang Road |
LMH to Frontier
Closed Area |
Contract 6 |
AM3 |
Ta Kwu Ling Fire
Service Station of Ta Kwu Ling Village. |
LMH to Frontier
Closed Area |
Contract 6 |
AM4b^ |
House no. 10B1 Nga Yiu Ha Village |
LMH to Frontier
Closed Area |
Contract 6 |
AM5a^ |
Ping Yeung
Village House |
Ping Yeung to
Wo Keng Shan |
Contract 6 |
AM6 |
Wo Keng Shan
Village House |
Ping Yeung to
Wo Keng Shan |
Contract 6 |
AM7b@ |
Loi Tung Village House |
Sha Tau Kok
Road |
Contract 2 Contract 6 |
AM8 |
Po Kat Tsai
Village No. 4 |
Po Kat Tsai |
Contract 2 |
AM9b# |
Nam Wa Po
Village House No. 80 |
Fanling |
Contract 3 |
# Proposal
for the change of air quality monitoring location from AM9a to AM9b was
submitted to EPD on 4 Nov 2013 after verified by the IEC and it was approved by
EPD (EPD¡¦s ref.: (15) in EP 2/N7/A/52 Pt.10 dated 8 Nov 2013).
@ Proposal for the change of air quality monitoring location from AM7a
to AM7b was submitted to EPD on 4 June 2014 after verified by the IEC. It was
approved by EPD (EPD¡¦s ref.: (7) in EP 2/N7/A/52 Pt.12 dated 9 Jun 2014).
^ Proposal for change
of air quality monitoring locations was enclosed in the updated EM&A
Programme which approval by EPD on 29 Mar 2016. Besides, Location AM1b was
temporary suspended (24-hour TSP monitoring) since 27 April 2018 as the rented
land was demolished and returned to the landlord.
* Revised proposal
for alterative location AM1c was submitted
to EPD on 31 October 2018 after
verified by the IEC and it was approved by EPD
(EPD¡¦s ref.: ( ) in Ax (1) to EP 2/N7/A/52 Pt.26 dated 26 November 2018)
Table 3-3 Impact
Monitoring Stations - Construction Noise
Station ID |
Description |
Works Area |
Related to the Work Contract |
NM1 |
Tsung Yuen Ha Village House No. 63 |
BCP |
SS C505 Contract 7 |
NM2a# |
Village House near Lin Ma Hang
Road |
Lin Ma Hang to Frontier Closed
Area |
Contract 6 |
NM3 |
Ping Yeung Village House (facade
facing northeast) |
Ping Yeung to Wo Keng Shan |
Contract 6 |
NM4 |
Wo Keng Shan Village House |
Ping Yeung to Wo Keng Shan |
Contract 6 |
NM5 |
Village House, Loi Tung |
Sha Tau Kok Road |
Contract 2, Contract 6 |
NM6 |
Tai Tong Wu Village House 2 |
Sha Tau Kok Road |
Contract 2, Contract 6 |
NM7 |
Po Kat Tsai Village |
Po Kat Tsai |
Contract 2 |
NM8 |
Village House, Tong Hang |
Fanling |
Contract 2 Contract 3 |
NM9 |
Village House, Kiu Tau Village |
Fanling |
Contract 3 |
NM10 |
Nam Wa Po Village House No. 80 |
Fanling |
Contract 3 |
# Proposal for the change of construction noise monitoring location from
NM2 to NM2a was verified by the IEC on 6 May 2016 and was effective on 9 May
2016.
Table 3-4 Impact
Monitoring Stations - Water Quality
Station ID |
Description |
Coordinates of Designated / Alternative Location |
Nature of the location |
Related to the Work Contract |
|
Easting |
Northing |
||||
WM1 |
Downstream of Kong Yiu Channel |
833 679 |
845 421 |
Alternative location located at upstream 51m of the designated location |
SS C505 Contract 6 |
WM1- Control |
Upstream of Kong Yiu Channel |
834 185 |
845 917 |
NA |
SS C505 Contract 6 |
WM2A |
Downstream of River Ganges |
834 204 |
844 471 |
Alternative location located at upstream 81m of the designated location |
Contract 6 |
WM2A(a)* |
Downstream of River Ganges |
834 191 |
844 474 |
Alternative location located at upstream 70m of the designated location |
Contract 6 |
WM2A- Controlx# |
Upstream of River Ganges |
835 377 |
844 188 |
Alternative location located at upstream 160m of the designated location |
Contract 6 |
WM2B |
Downstream of River Ganges |
835 433 |
843 397 |
NA |
Contract 6 |
WM2B- Control |
Upstream of River Ganges |
835 835 |
843 351 |
Alternative location located at downstream 31m of the designated
location |
Contract 6 |
WM3x# |
Downstream of River Indus |
836 206 |
842 270 |
Alternative location located at downstream 180m of the designated
location |
Contract 2 Contract 6 |
WM3- Control |
Upstream of River Indus |
836 763 |
842 400 |
Alternative location located at downstream 26m of the designated
location |
Contract 2 Contract 6 |
WM4 |
Downstream of Ma Wat Channel |
833 850 |
838 338 |
Alternative location located at upstream 11m of the designated location |
Contract 2 Contract 3 |
WM4¡V Control A |
Kau Lung Hang Stream |
834 028 |
837 695 |
Alternative location located at downstream 28m of the designated
location |
Contract 2 Contract 3 |
WM4¡V Control B |
Upstream of Ma Wat Channel |
833760 |
837395 |
Alternative location located at upstream 15m of the designated location |
Contract 2 Contract 3 |
Note: EPD has
approved the revised EM&A Programme (Rev.7) which proposed that (1) if the measured
water depth of the monitoring station is lower than 150 mm, alternative
location based on the criteria were selected to perform water monitoring; and
(2) If no suitable alternative location could be found within 15m far from the
original location, the sampling at that location will be cancelled since
sampling at too far from the designated location could not make a
representative sample in accordance with the updated EM&A Programme (Rev.
07) (Section 4.1.4) (EPD ref.: ( ) in EP2/N7/A/52 Ax(1) Pt.20 dated 7 April
2017)
(*)
Proposal for the
change of water monitoring location from WM2A to WM2A(a) was verified by the
IEC and it was approved by EPD. (EPD¡¦s ref. (10) in EP 2/N7/A/52 Pt.19)
(#) Proposal for the change of water quality monitoring location (WM3x and WM2A-Cx was included in the EM&A Programme Rev .05 which approved by EPD on 29 March
2016 (EPD ref.: (3) in EP2/N7/A/52 Ax(1) Pt.19)
The requirements of impact monitoring are stipulated in Sections 2.1.6, 3.1.5 and 4.1.6 of the approved EM&A Manual and presented as
follows.
Air Quality Monitoring
3.4.1
Frequency of impact air quality monitoring is
as follows:
1-hour TSP |
3 times every six
days during course of works |
24-hour TSP |
Once every 6 days during
course of works. |
Noise Monitoring
3.4.2
One set of Leq(30min) as 6
consecutive Leq(5min) between 0700-1900 hours on normal weekdays and
once every week during course of works.
If construction work necessary to carry out at other time periods, i.e.
restricted time period (19:00 to 07:00 the next morning and whole day on public
holidays) (hereinafter referred as ¡§the restricted hours¡¨), additional weekly
impact monitoring for Leq(5min) measurement shall be employed during
respective restricted hours periods..
Supplementary information for data auditing, statistical results such as
L10 and L90 shall also be obtained for reference.
Water Quality Monitoring
3.4.3
The water quality monitoring frequency shall
be 3 days per week during course of works.
The interval between two sets of monitoring shall not be less than 36
hours.
Air Quality Monitoring
3.5.1
The 24-hour and 1-hour TSP levels shall be
measured by following the standard high volume sampling method as set out in
the Title 40 of the Code of Federal
Regulations, Chapter 1 (Part 50), Appendix
B. If the ET proposes to
use a direct reading dust meter to measure 1-hour TSP levels, it shall submit
sufficient information to the IEC to approve.
3.5.2
The filter paper of
24-hour TSP measurement shall be determined by HOKLAS accredited laboratory.
3.5.3
All equipment to be used for air quality
monitoring is listed in Table 3-5.
Table 3-5 Air
Quality Monitoring Equipment
Equipment |
Model |
24-Hr TSP |
|
High
Volume Air Sampler |
TISCH High Volume
Air Sampler, HVS Model TE-5170* |
Calibration
Kit |
TISCH Model
TE-5025A* |
1-Hour TSP |
|
Portable Dust Meter |
Sibata LD-3B Laser
Dust monitor Particle Mass Profiler & Counter* |
* Instrument was used in the Reporting
Period and the calibration certificate could be referred in Appendix F.
Wind Data Monitoring Equipment
3.5.4
According to the approved EM&A Manual,
wind data monitoring equipment shall also be provided and set up for logging wind
speed and wind direction near the dust monitoring locations. The equipment installation location
shall be proposed by the ET and agreed with the IEC. For installation and operation of wind
data monitoring equipment, the following points shall be observed:
1)
The wind sensors should be installed 10 m
above ground so that they are clear of obstructions or turbulence caused by
buildings.
2)
The wind data should be captured by a data
logger. The data shall be downloaded for analysis at least once a month.
3)
The wind data monitoring equipment should be
re-calibrated at least once every six months.
4)
Wind direction should be divided into 16
sectors of 22.5 degrees each.
3.5.5
ET has liaised with the landlords of the
successful granted HVS installation premises. However, the owners rejected to provide
premises for wind data monitoring equipment installation.
3.5.6
Under this situation, the ET proposed
alternative methods to obtain representative wind data. Meteorological information as extracted
from ¡§the Hong Kong Observatory Ta Kwu Ling Station¡¨ is alternative method to
obtain representative wind data.
For Ta Kwu Ling Station, it is located nearby the Project site. Moreover, this station is located at 15m
above mean sea level while its anemometer is located at 13m above the existing
ground which in compliance with the general setting up requirement. Furthermore, this station also can be to
provide the humidity, rainfall, and air pressure and temperature etc.
meteorological information. In Hong
Kong of a lot development projects, weather information extracted from Hong
Kong Observatory is common alternative method if weather station installation
not allowed.
Noise Monitoring
3.5.7
Sound level meter in compliance with the
International Electrotechnical Commission Publications 651: 1979 (Type 1) and
804: 1985 (Type 1) specifications shall be used for carrying out the noise
monitoring. The sound level meter
shall be checked using an acoustic calibrator. The wind speed shall be checked with a
portable wind speed meter capable of measuring the wind speed in m/s.
3.5.8
Noise monitoring equipment to be used for
monitoring is listed in Table 3-6.
Table 3-6 Construction
Noise Monitoring Equipment
Equipment |
Model |
Integrating Sound Level Meter |
B&K Type 2238* and Rion NL-52* |
Calibrator |
Rion NC-74* |
Portable Wind Speed Indicator |
Testo Anemometer |
* Instrument was used in the Reporting
Period and the calibration certificate could be referred in Appendix F.
3.5.9
Sound level meters listed above comply with
the International Electrotechnical
Commission Publications 651: 1979 (Type 1) and 804: 1985 (Type 1) specifications, as recommended in TM issued
under the NCO. The acoustic
calibrator and sound level meter to be used in the impact monitoring will be
calibrated yearly.
Water Quality Monitoring
3.5.10
DO and water temperature should be measured
in-situ by a DO/temperature meter. The instrument should be portable and
weatherproof using a DC power source. It should have a membrane electrode with automatic
temperature compensation complete with a cable. The equipment should be capable
of measuring:
•
a DO level in the range of 0-20 mg/l and
0-200% saturation; and
•
a temperature of between 0 and 45 degree
Celsius.
3.5.11
A portable pH meter capable of measuring a
range between 0.0 and 14.0 should be provided to measure pH under the specified
conditions accordingly to the APHA Standard Methods.
3.5.12
The instrument should be portable and
weatherproof using a DC power source. It should have a photoelectric sensor capable
of measuring turbidity between 0-1000 NTU.
3.5.13
A portable, battery-operated echo sounder or
tape measure will be used for the determination of water depth at each
designated monitoring station as appropriate.
3.5.14
A water sampler e.g. Kahlsico Water Sampler,
which is a transparent PVC cylinder with capacity not less than 2 litres, will
be used for water sampling if water depth over than 0.5m. For sampling from very shallow
water depths e.g. <0.5 m, water sample collection will be directly from
water surface below 100mm use sampling plastic bottle to avoid inclusion of
bottom sediment or humus. Moreover,
Teflon/stainless steel bailer or self-made sampling buckets maybe used for
water sampling. The equipment used
for sampling will be depended the sampling location and depth situations.
3.5.15
Water samples for laboratory measurement of
SS will be collected in high density polythene bottles, packed in ice (cooled
to 4 ºC without being frozen), and delivered to the laboratory in the same day as
the samples were collected.
3.5.16
Analysis of suspended solids should be
carried out in a HOKLAS or other accredited laboratory. Water samples of about
1L should be collected at the monitoring stations for carrying out the
laboratory suspended solids determination.
The SS determination work should start within 24 hours after collection
of the water samples. The SS analyses should follow the APHA Standard Methods 2540D with Limit of Reporting of 2 mg/L.
3.5.17
Water quality monitoring equipment used in
the impact monitoring is listed in Table 3-7. Suspended solids (SS)
analysis is carried out by a local HOKLAS-accredited laboratory, namely ALS Technichem (HK) Pty Ltd.
Table 3-7 Water
Quality Monitoring Equipment
Equipment |
Model |
Water Depth Detector |
Eagle Sonar or tape measures |
Water Sampler |
A 2-litre transparent PVC cylinder with latex cups at
both ends or teflon/stainless steel bailer or self-made sampling bucket |
Thermometer & DO meter |
YSI Professional Plus /YSI PRO20 Handheld Dissolved Oxygen
Instrument*/ YSI 550A Multifunctional Meter/ YSI Professional DSS |
pH meter |
YSI Professional Plus / AZ8685 pH pen-style meter*/ YSI 6820/ 650MDS/ YSI Professional DSS |
Turbidimeter |
Hach 2100Q*/ YSI 6820/ 650MDS/ YSI Professional DSS |
Sample Container |
High density polythene bottles (provided by laboratory) |
Storage Container |
¡¥Willow¡¦ 33-liter plastic cool box with Ice pad |
* Instrument was used in the Reporting
Period and the calibration certificate could be referred in Appendix F.
1-hour TSP
Monitoring
3.6.1
The 1-hour TSP monitor was a brand named
¡§Sibata LD-3B Laser Dust monitor Particle Mass Profiler & Counter¡¨ which is
a portable, battery-operated laser photometer. The 1-hour TSP meter provides a real
time 1-hour TSP measurement based on 90o light scattering. The 1-hour TSP monitor consists of the
following:
(a.)
A pump to draw sample aerosol through the
optic chamber where TSP is measured;
(b.)
A sheath air system to isolate the aerosol in
the chamber to keep the optics clean for maximum reliability; and
(c.)
A built-in data logger compatible with
Windows based program to facilitate data collection, analysis and reporting.
3.6.2
The 1-hour TSP meter is used within the valid
period as follow manufacturer¡¦s Operation and Service Manual.
3.6.3
The equipment used for 24-hour TSP
measurement is Tisch
Environmental, Inc. Model TE-5170 TSP high volume air sampling system, which
complied with EPA Code of Federal Regulation,
Appendix B to Part 50. The High Volume Air Sampler (HVS) consists of the
following:
(a.)
An anodized aluminum shelter;
(b.)
A 8¡¨x10¡¨ stainless steel filter holder;
(c.)
A blower motor assembly;
(d.)
A continuous flow/pressure recorder;
(e.)
A motor speed-voltage control/elapsed time
indicator;
(f.)
A 7-day mechanical timer, and
(g.)
A power supply of 220v/50 Hz
3.6.4
The HVS is operated and calibrated on a
regular basis in accordance with the manufacturer¡¦s instruction using Tisch
Calibration Kit Model TE-5025A.
Calibration would carry out in two month interval.
3.6.5
24-hour TSP is collected by the ET on filters
of HVS and quantified by a local HOKLAS accredited laboratory, ALS Technichem
(HK) Pty Ltd (ALS), upon receipt of the samples. The ET keep all the sampled 24-hour TSP
filters in normal air conditioned room conditions, i.e. 70% RH (Relative
Humidity) and 25oC, for six months prior to disposal.
3.6.6
Noise measurements were taken in terms of the
A-weighted equivalent sound pressure level (Leq) measured in
decibels dB(A). Supplementary statistical results (L10 and L90)
were also obtained for reference.
3.6.7
During the monitoring, all noise measurements
would be performed with the meter set to FAST response and on the A-weighted
equivalent continuous sound pressure level (Leq). Leq(30min) in six consecutive
Leq(5min) measurements will use as the monitoring parameter for the
time period between 0700-1900 hours on weekdays; Leq(5min) measurements
would be used as monitoring parameter for other time periods (e.g. during
restricted hours), if necessary.
3.6.8
Prior of noise measurement, the accuracy of
the sound level meter is checked using an acoustic calibrator generating a
known sound pressure level at a known frequency. The checking is performed before and
after the noise measurement.
Water
Quality
3.6.9
Water quality monitoring is conducted at the
designated or alternative locations. The sampling procedures with the in-situ
monitoring are presented as below:
Sampling Procedure
3.6.10
A Digital Global
Positioning System (GPS) is used to identify the designated monitoring stations
prior to water sampling. A
portable, battery-operated echo sounder or tape measurement is used for the
determination of water depth at each station. At each station, water sample would be
collected from 0.1m below water surface or the water surface to prevent the
river bed sediment for stirring.
3.6.11
If the water level of a
monitoring station is too shallow when sampling, sediment would be disturbed
which affecting the accuracy of water quality monitoring. In order to avoid disturbing sediment,
depth limits should be set up for the water sampling for the ease of
reference. When the measured water
depth of the monitoring station (both control and impact stations) is lower than
150mm, water monitoring would not be to perform at that monitoring
location. Instead, the monitoring
location will be moved to a temporary alternative location monitoring location
based on the criteria below:-
(a) the alternative location should be either
upstream or downstream of the original location and at the same the
river/drain channel
(b) the alternative location should be within 15m far from the original location
(c) if no suitable alternative location could be
found within 15m far from the original location,
the sampling at that location will be cancelled since sampling at too far from
the designated location could not make a representative sample.
3.6.12
The sample container will be rinsed with a
portion of the water sample. The
water sample then will be transferred to the high-density polythene bottles as provided by the laboratory,
labeled with a unique sample number and sealed with a screw cap.
3.6.13
Before sampling, general information such as
the date and time of sampling, weather condition as well as the personnel
responsible for the monitoring would be recorded on the field data sheet.
3.6.14
A ¡¥Willow¡¦ 33-liter plastic cool box packed
with ice will be used to preserve the water samples prior to arrival at the
laboratory for chemical determination.
The water temperature of the cool box is maintained at a temperature as
close to 40C as possible without being frozen. Samples collected are delivered to the
laboratory upon collection.
In-situ Measurement
3.6.15
YSI PRO20 Handheld Dissolved Oxygen
Instrument is used for water in-situ measures,
which automates the measurements and data logging of temperature, dissolved
oxygen and dissolved oxygen saturation.
3.6.16
A portable AZ Model 8685 is used for in-situ
pH measurement. The pH meter is
capable of measuring pH in the range of 0 ¡V 14 and readable to 0.1.
3.6.17
A portable Hach 2100Q Turbidimeter is used
for in-situ turbidity measurement. The turbidity meter is capable of measuring
turbidity in the range of 0 ¡V 1000 NTU.
3.6.18
All in-situ measurement equipment are calibrated
by HOKLAS accredited laboratory of three month interval.
Laboratory Analysis
3.6.19
All water samples analyzed Suspended Solids
(SS) will be carried out by a local HOKLAS-accredited testing laboratory (ALS
Technichem (HK) Pty Ltd HOKLAS registration no. 66). SS determination using APHA
Standard Methods 2540D as specified in the EM&A Manual will start within
48 hours of water sample receipt.
3.7.1
Calibration of the HVS is performed upon installation
and thereafter at bimonthly intervals in accordance with the manufacturer¡¦s
instruction using the certified standard calibrator (TISCH Model TE-5025A). Moreover, the
Calibration Kit would be calibrated annually. The
calibration data are properly documented and the records are maintained by ET
for future reference.
3.7.2
The 1-hour TSP
meter was calibrated by the supplier prior to purchase. Zero response of the equipment would be
checked before and after each monitoring event. Annually calibration with the High
Volume Sampler (HVS) in same condition would be undertaken by the Laboratory.
3.7.3
The sound level
meter and calibrator are calibrated and certified by a laboratory accredited
under HOKLAS or any other international accreditation scheme at yearly basis.
3.7.4
All water quality monitoring equipment would
be calibrated by HOKLAS accredited laboratory of three month intervals.
3.7.5
The calibration
certificates of all monitoring equipment used for the impact monitoring program
in the Reporting Period and the HOKLAS accredited certificate of laboratory are attached in Appendix F.
3.8.1
The baseline results form the basis for
determining the environmental acceptance criteria for the impact
monitoring. According to the approved
Environmental Monitoring and Audit Manual, the air quality, construction noise
and water quality criteria were set up, namely Action and Limit levels are
listed in Tables 3-8, 3-9 and 3-10.
Table 3-8 Action and
Limit Levels for Air Quality Monitoring
Monitoring
Station |
Action Level (mg /m3) |
Limit Level (mg/m3) |
||
1-hour TSP |
24-hour TSP |
1-hour TSP |
24-hour TSP |
|
AM1c |
265 |
143 |
500 |
260 |
AM2 |
268 |
149 |
||
AM3 |
269 |
145 |
||
AM4b |
267 |
148 |
||
AM5a |
268 |
143 |
||
AM6 |
269 |
148 |
||
AM7b |
275 |
156 |
||
AM8 |
269 |
144 |
||
AM9b |
271 |
151 |
Table 3-9 Action
and Limit Levels for Construction Noise
Monitoring Location |
Action Level |
Limit Level in
dB(A) |
Time Period:
0700-1900 hours on normal weekdays |
||
NM1, NM2a, NM3,
NM4, NM5, NM6, NM7, NM8, NM9, NM10 |
When one
or more documented complaints are received |
75 dB(A)Note 1
& Note 2 |
Note 1: Acceptable Noise Levels
for school should be reduced to 70 dB(A) and65 dB(A)
during examination period.
Note 2: If works are to be
carried out during restricted hours, the conditions stipulated in the construction noise permit issued by the NCA have to be followed.
Table 3-10 Action and
Limit Levels for Water Quality
Parameter |
Performance
criteria |
Monitoring Location |
|||||
WM1 |
WM2A(a) |
WM2B |
WM3x |
WM4 |
|||
DO (mg/L) |
Action Level |
(*)4.23 |
(**)4.00 |
(*)4.74 |
(**)4.00 |
(*)4.14 |
|
Limit Level |
(#)4.19 |
(**)4.00 |
(#)4.60 |
(**)4.00 |
(#)4.08 |
||
Turbidity (NTU) |
Action Level |
51.3 |
24.9 |
11.4 |
13.4 |
35.2 |
|
AND 120% of upstream control station of
the same day |
|||||||
Limit Level |
67.6 |
33.8 |
12.3 |
14.0 |
38.4 |
||
AND 130% of upstream control station of the same day |
|||||||
SS (mg/L) |
Action Level |
54.5 |
14.6 |
11.8 |
12.6 |
39.4 |
|
AND 120% of upstream control station of the
same day |
|||||||
Limit Level |
64.9 |
17.3 |
12.4 |
12.9 |
45.5 |
||
AND 130% of upstream control station of the same day |
|||||||
Remarks: (*) The
Proposed Action Level of Dissolved
Oxygen is adopted to be used 5%-ile of baseline data (**) The
Proposed Action & Limit Level of Dissolved
Oxygen is used 4mg/L (#) The
Proposed Limit Level of Dissolved
Oxygen is adopted to be used 1%-ile of baseline data |
|||||||
3.8.2
Should non-compliance of the environmental
quality criteria occurs, remedial actions will be triggered according to the
Event and Action Plan which presented in Appendix G.
3.9.1
All monitoring data will be handled by the ET¡¦s in-house data recording and management system. The monitoring data
recorded in the equipment will be downloaded directly from the equipment at the
end of each monitoring day. The
downloaded monitoring data will input into a computerized database maintained
by the ET. The laboratory results
will be input directly into the computerized database and checked by personnel
other than those who input the data.
3.9.2
For monitoring parameters that require
laboratory analysis, the local laboratory shall follow the QA/QC requirements
as set out under the HOKLAS scheme for the relevant laboratory tests.
4.1.1
In the Reporting Period, construction works under the
project have been commenced in Contracts
2, 3, 4, 6, 7 and
Contract SS C505. Hence, air quality monitoring was performed at all designated
locations.
4.1.2
The air quality monitoring schedule is
presented in Appendix H and the monitoring results are summarized in the
following sub-sections.
4.2.1
In the Reporting Period, a total of 150 events of 1-hour TSP and 49 events 24-hours TSP monitoring were carried
out and the monitoring results are summarized in Tables 4-1 to 4-9. The detailed 24-hour TSP monitoring data
are presented in Appendix I and the relevant graphical plots are shown in Appendix
J.
Table 4-1 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM1c
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
1-Feb-19 |
33
|
2-Feb-19 |
9:41 |
56 |
59 |
55 |
4-Feb-19 |
71
|
8-Feb-19 |
9:17 |
101 |
103 |
105 |
9-Feb-19 |
35
|
14-Feb-19 |
9:09 |
56 |
58 |
60 |
15-Feb-19 |
80
|
20-Feb-19 |
9:14 |
59 |
61 |
62 |
21-Feb-19 |
27
|
26-Feb-19 |
9:19 |
74 |
77 |
75 |
27-Feb-19 |
40
|
-- |
-- |
-- |
-- |
-- |
Average (Range) |
48 (27-80) |
Average (Range) |
71 (55 ¡V 105) |
Table 4-2 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM2
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
1-Feb-19 |
148
|
2-Feb-19 |
9:25 |
155 |
143 |
150 |
4-Feb-19 |
149
|
8-Feb-19 |
9:23 |
148 |
156 |
160 |
9-Feb-19 |
58
|
14-Feb-19 |
9:14 |
58 |
60 |
64 |
15-Feb-19 |
147
|
20-Feb-19 |
9:19 |
149 |
150 |
138 |
21-Feb-19 |
127
|
26-Feb-19 |
9:24 |
81 |
84 |
87 |
27-Feb-19 |
140
|
-- |
-- |
-- |
-- |
-- |
Average (Range) |
128 (58 ¡V 149) |
Average (Range) |
119 (58 ¡V 160) |
Table 4-3 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM3
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
1-Feb-19 |
47
|
2-Feb-19 |
13:27 |
59 |
57 |
61 |
4-Feb-19 |
122
|
8-Feb-19 |
9:28 |
107 |
112 |
103 |
9-Feb-19 |
44
|
14-Feb-19 |
9:17 |
62 |
65 |
68 |
15-Feb-19 |
69
|
20-Feb-19 |
9:22 |
58 |
59 |
63 |
21-Feb-19 |
28
|
26-Feb-19 |
9:27 |
77 |
81 |
82 |
27-Feb-19 |
94
|
-- |
-- |
-- |
-- |
-- |
Average (Range) |
67 (28 ¡V 122) |
Average (Range) |
74 (57 ¡V 112) |
Table 4-4 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM4b
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
2-Feb-19 |
74
|
1-Feb-19 |
9:42 |
65 |
66 |
69 |
8-Feb-19 |
56
|
4-Feb-19 |
9:12 |
74 |
70 |
68 |
14-Feb-19 |
63
|
9-Feb-19 |
9:43 |
54 |
57 |
60 |
20-Feb-19 |
81
|
15-Feb-19 |
9:05 |
62 |
65 |
65 |
26-Feb-19 |
66
|
21-Feb-19 |
9:25 |
75 |
72 |
74 |
-- |
-- |
27-Feb-19 |
9:34 |
70 |
80 |
73 |
Average (Range) |
68 (56 ¡V 81) |
Average (Range) |
68 (54 ¡V 80) |
Table 4-5 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM5a
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
2-Feb-19 |
98
|
1-Feb-19 |
9:39 |
96 |
110 |
101 |
8-Feb-19 |
121
|
4-Feb-19 |
9:34 |
90 |
94 |
103 |
14-Feb-19 |
65
|
9-Feb-19 |
9:40 |
124 |
136 |
118 |
20-Feb-19 |
38
|
15-Feb-19 |
9:10 |
65 |
57 |
58 |
26-Feb-19 |
85
|
21-Feb-19 |
9:20 |
67 |
66 |
65 |
-- |
-- |
27-Feb-19 |
9:31 |
71 |
65 |
62 |
Average (Range) |
81 (38 ¡V 121) |
Average (Range) |
86 (57 ¡V 136) |
|
|
Table 4-6 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM6
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
2-Feb-19 |
138
|
1-Feb-19 |
9:31 |
110 |
108 |
120 |
8-Feb-19 |
94
|
4-Feb-19 |
9:47 |
89 |
90 |
86 |
14-Feb-19 |
79
|
9-Feb-19 |
9:32 |
56 |
59 |
61 |
20-Feb-19 |
116
|
15-Feb-19 |
9:25 |
63 |
54 |
66 |
26-Feb-19 |
103
|
21-Feb-19 |
9:10 |
123 |
136 |
120 |
-- |
-- |
27-Feb-19 |
9:23 |
117 |
98 |
108 |
Average (Range) |
106 (79 ¡V 138) |
Average (Range) |
92 (54 ¡V 136) |
Table 4-7 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM7b
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
2-Feb-19 |
43
|
1-Feb-19 |
9:24 |
65 |
67 |
70 |
8-Feb-19 |
139
|
4-Feb-19 |
13:02 |
113 |
108 |
112 |
14-Feb-19 |
55
|
9-Feb-19 |
9:25 |
130 |
128 |
118 |
20-Feb-19 |
63
|
15-Feb-19 |
12:56 |
52 |
56 |
58 |
26-Feb-19 |
75
|
21-Feb-19 |
9:31 |
62 |
59 |
61 |
-- |
-- |
27-Feb-19 |
9:18 |
71 |
74 |
77 |
Average (Range) |
75 (43 ¡V 139) |
Average (Range) |
82 (52¡V 130) |
Table 4-8 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM8
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
2-Feb-19 |
50
|
1-Feb-19 |
9:12 |
59 |
61 |
66 |
8-Feb-19 |
27
|
4-Feb-19 |
13:02 |
46 |
60 |
52 |
14-Feb-19 |
34
|
9-Feb-19 |
9:14 |
59 |
61 |
64 |
20-Feb-19 |
25
|
15-Feb-19 |
12:48 |
56 |
58 |
60 |
26-Feb-19 |
139
|
21-Feb-19 |
13:45 |
59 |
60 |
58 |
-- |
-- |
27-Feb-19 |
9:03 |
120 |
112 |
122 |
Average (Range) |
55 (25 ¡V 139) |
Average (Range) |
69 (46 ¡V 122) |
Table 4-9 Summary
of 24-hour and 1-hour TSP Monitoring Results ¡V AM9b
Date |
24-hour
TSP (mg/m3) |
1-hour
TSP (mg/m3) |
||||
Date |
Start Time |
1st
reading |
2nd
reading |
3rd
reading |
||
1-Feb-19 |
112
|
2-Feb-19 |
9:10 |
121 |
130 |
114 |
4-Feb-19 |
60
|
8-Feb-19 |
14:13 |
55 |
58 |
62 |
9-Feb-19 |
78
|
14-Feb-19 |
9:28 |
87 |
80 |
78 |
15-Feb-19 |
89
|
20-Feb-19 |
13:01 |
47 |
51 |
55 |
21-Feb-19 |
54
|
26-Feb-19 |
9:23 |
57 |
59 |
56 |
27-Feb-19 |
61
|
-- |
-- |
-- |
-- |
-- |
Average (Range) |
76 (54 ¡V 112) |
Average (Range) |
74 (47 ¡V 130) |
4.2.2
As shown in Tables 4-1 to 4-9, all
the 1-hour and 24-hour TSP monitoring
results were below the Action/Limit Levels. No Notification of Exceedance (NOE) was
issued in this Reporting Period.
4.2.3
The meteorological data during the impact
monitoring days are summarized in Appendix K.
5.1.1
In the Reporting Period, construction works under the
project have been commenced in Contracts
2, 3, 4, 6, 7 and
Contract SS C505 and noise monitoring was performed at all designated
locations.
5.1.2
The noise monitoring schedule is presented in
Appendix
H and the monitoring results are summarized in the following
sub-sections.
5.2.1
In the Reporting Period, a total of 45 events noise measurements were carried out at the
designated locations. The sound
level meter was set in 1m from the exterior of the building façade including
noise monitoring locations NM1, NM3, NM4, NM5, NM6, NM7, NM8 and NM9. Therefore, no façade correction (+3
dB(A)) is added according to acoustical principles and EPD guidelines. However, free-field status were
performed at NM2a and NM10 and façade correction (+3 dB(A)) has added according
to the requirement in this month.
The noise monitoring results at the designated locations are summarized
in Tables
5-1 and 5-2. The detailed
noise monitoring data are presented in Appendix I and the relevant
graphical plots are shown in Appendix J.
Table 5-1 Summary of Construction Noise Monitoring Results
Construction Noise Level (Leq30min), dB(A) |
|||||
Date |
NM1 |
NM2a(*) |
NM8 |
NM9 |
NM10(*) |
8-Feb-19 |
54
|
67 |
59 |
59 |
59 |
14-Feb-19 |
57
|
70 |
60 |
70 |
65 |
20-Feb-19 |
57
|
70 |
60 |
63 |
66 |
26-Feb-19 |
57
|
68 |
60 |
66 |
71 |
Limit Level |
75 dB(A) |
Remarks
(*) façade
correction (+3 dB(A) is added according to acoustical principles and EPD
guidelines
Table 5-2 Summary of Construction Noise Monitoring Results
Construction Noise Level (Leq30min), dB(A) |
|
|||||||
Date |
NM3 |
NM4 |
NM5 |
NM6 |
NM7 |
|
||
1-Feb-19 |
59
|
64
|
59 |
54 |
59 |
|
||
4-Feb-19 |
57
|
64
|
51 |
57 |
56 |
|
||
15-Feb-19 |
60
|
65
|
54 |
58 |
56 |
|
||
21-Feb-19 |
61
|
64
|
62 |
59 |
64 |
|
||
27-Feb-19 |
60
|
65
|
53 |
58 |
54 |
|
||
Limit Level |
75 dB(A) |
|
|
54 |
5.2.2
As shown in Tables
5-1 and 5-2, no construction
noise measurement results that exceeded the Limit Level were recorded. Moreover,
no valid noise complaint (which triggered Action Level exceedance) was recorded
in the Reporting Period.
6.1.1
In the Reporting Period, construction works under the
project has been commenced in Contracts
2, 3, 4, 6, 7 and
Contract SS C505 and water quality monitoring was performed at all designated
locations. The water quality
monitoring schedule is presented in Appendix H. The monitoring results are summarized in
the following sub-sections.
6.2.1
There was site
closure for all Contracts except for Contract 2 during Lunar New Year Holiday on 5 to 7 February
2019. As advised by the Contractor
of Contract 2, wastewater generated from construction site has been limited to
wheel washing for some private vehicles and groundwater seepage inside
waterproof tunnel. With the implementation of wastewater treatment facilities,
it was considered that the water quality impact was negligible and therefore
water quality monitoring was suspended on 5 to 7 February 2019.
6.2.2
In the Reporting Period, a total of eleven (11) sampling days were scheduled
to carry out for all designated locations with their control stations. Since exceedance was recorded at WM2A(a) and WM4, according to ¡§Event and Action Plan¡¨ stipulation, 1 additional water quality monitoring day was conducted for WM2A(a) and WM4
and its control station respectively.
6.2.3
The key monitoring parameters including Dissolved Oxygen, Turbidity and Suspended
Solids are summarized in Tables 6-1 to 6-5. Breaches of water quality monitoring
criteria are shown in Table 6-6. Detailed monitoring database including
in-situ measurements and laboratory analysis data are shown in Appendix
I and the relevant graphical plot are shown in Appendix J.
Table 6-1 Water
Quality Monitoring Results Associated of Contracts 2 and 3
Date |
Dissolved Oxygen (mg/L) |
Turbidity (NTU) |
Suspended Solids (mg/L) |
||||||
WM4 |
WM4-CA |
WM4-CB |
WM4 |
WM4-CA |
WM4-CB |
WM4 |
WM4-CA |
WM4-CB |
|
1-Feb-19 |
8.2 |
9.6 |
5.9 |
17.1 |
3.0 |
7.0 |
19.0 |
3.0 |
7.5 |
4-Feb-19 |
7.7 |
9.5 |
5.8 |
5.2 |
3.6 |
8.1 |
5.5 |
2.0 |
8.0 |
8-Feb-19 |
7.6 |
9.1 |
5.8 |
12.8 |
5.2 |
8.6 |
12.0 |
2.0 |
10.0 |
11-Feb-19 |
7.7 |
9.6 |
5.3 |
11.2 |
4.6 |
8.4 |
10.5 |
10.0 |
8.5 |
13-Feb-19 |
7.5 |
9.2 |
4.9 |
13.6 |
3.2 |
6.8 |
11.5 |
<2 |
7.0 |
15-Feb-19 |
7.6 |
9.1 |
6.0 |
15.4 |
9.9 |
9.6 |
20.5 |
2.0 |
10.5 |
18-Feb-19 |
7.6 |
8.1 |
5.2 |
28.6 |
13.0 |
14.3 |
31.5 |
28.5 |
21.5 |
20-Feb-19 |
7.6 |
8.3 |
5.3 |
25.9 |
4.2 |
10.8 |
38.5 |
10.0 |
15.0 |
22-Feb-19 |
7.6 |
9.2 |
4.9 |
11.5 |
5.5 |
9.2 |
9.0 |
<2 |
8.0 |
25-Feb-19 |
7.6 |
9.3 |
5.4 |
73.9 |
11.7 |
12.5 |
78.5 |
2.5 |
12.0 |
26-Feb-19# |
# |
# |
# |
11.7 |
5.0 |
8.5 |
14.0 |
6.0 |
12.0 |
27-Feb-19 |
7.6 |
9.2 |
6.0 |
16.3 |
5.4 |
10.8 |
16.0 |
<2 |
10.5 |
Bold and underline indicated Limit Level
exceedance Remarks: (#) Additional water
quality monitoring was conducted according to ¡§Event and Action Plan¡¨
stipulation. |
|
Table 6-2 Water Quality
Monitoring Results Associated of Contracts 6 and SS C505
Date |
Dissolved Oxygen (mg/L) |
Turbidity (NTU) |
Suspended Solids (mg/L) |
|||
WM1 |
WM1-C |
WM1 |
WM1-C |
WM1 |
WM1-C |
|
1-Feb-19 |
7.7 |
11.7 |
12.1 |
8.3 |
16.0 |
11.0 |
4-Feb-19 |
7.1 |
7.9 |
11.1 |
16.5 |
21.5 |
13.5 |
8-Feb-19 |
6.6 |
6.8 |
13.3 |
13.5 |
16.0 |
9.5 |
11-Feb-19 |
6.9 |
8.4 |
11.3 |
11.5 |
9.0 |
12.5 |
13-Feb-19 |
6.9 |
7.6 |
28.7 |
20.0 |
33.5 |
15.5 |
15-Feb-19 |
5.6 |
6.3 |
13.7 |
20.6 |
15.5 |
20.0 |
18-Feb-19 |
6.8 |
8.7 |
12.3 |
9.8 |
15.0 |
9.0 |
20-Feb-19 |
6.2 |
6.4 |
over range |
over range |
825.0 |
760.5 |
22-Feb-19 |
4.9 |
5.5 |
126.5 |
153.0 |
86.0 |
106.5 |
25-Feb-19 |
6.2 |
5.8 |
146.5 |
174.5 |
90.5 |
97.5 |
27-Feb-19 |
8.1 |
5.3 |
39.7 |
132.5 |
25.0 |
95.0 |
|
Table 6-3 Water
Quality Monitoring Results Associated only Contract 6
Date |
Dissolved Oxygen (mg/L) |
Turbidity (NTU) |
Suspended Solids (mg/L) |
|||||||||
WM2A(a) |
WM2A- Cx |
WM2B |
WM2B- C |
WM2A(a) |
WM2A- Cx |
WM2B |
WM2B- C |
WM2A(a) |
WM2A- Cx |
WM2B |
WM2B- C |
|
1-Feb-19 |
10.0 |
9.0 |
* |
* |
4.3 |
14.2 |
* |
* |
2.5 |
5.5 |
* |
* |
4-Feb-19 |
9.2 |
8.6 |
* |
* |
21.7 |
11.7 |
* |
* |
10.0 |
4.5 |
* |
* |
8-Feb-19 |
8.5 |
8.5 |
* |
* |
67.9 |
12.0 |
* |
* |
89.5 |
3.0 |
* |
* |
9-Feb-19# |
# |
# |
* |
* |
9.7 |
8.9 |
* |
* |
3.0 |
<2 |
* |
* |
11-Feb-19 |
9.5 |
9.0 |
* |
* |
5.1 |
9.8 |
* |
* |
5.5 |
3.5 |
* |
* |
13-Feb-19 |
9.4 |
8.5 |
* |
* |
6.1 |
15.8 |
* |
* |
2.0 |
4.5 |
* |
* |
15-Feb-19 |
9.3 |
8.4 |
* |
* |
9.5 |
14.9 |
* |
* |
6.0 |
<2 |
* |
* |
18-Feb-19 |
9.2 |
8.7 |
* |
* |
10.3 |
25.8 |
* |
* |
6.0 |
18.0 |
* |
* |
20-Feb-19 |
7.9 |
8.0 |
* |
* |
92.6 |
82.6 |
* |
* |
65.0 |
57.5 |
* |
* |
22-Feb-19 |
8.2 |
7.6 |
* |
* |
44.3 |
45.9 |
* |
* |
19.0 |
25.5 |
* |
* |
25-Feb-19 |
9.2 |
8.7 |
* |
* |
17.2 |
20.4 |
* |
* |
9.5 |
8.5 |
* |
* |
27-Feb-19 |
9.2 |
8.4 |
* |
* |
23.8 |
24.1 |
* |
* |
7.5 |
6.5 |
* |
* |
Remarks: * water sampling was unable to carry out at WM2B
and WM2B-C due to shallow water (water depth under 150mm (#) Additional water quality monitoring was conducted according
to ¡§Event and Action Plan¡¨ stipulation. Bold and underline indicated
Limit Level exceedance |
Table 6-4 Water
Quality Monitoring Results Associated Contracts 2 and 6
Date |
Dissolved Oxygen (mg/L) |
Turbidity (NTU) |
Suspended Solids (mg/L) |
|||
WM3x |
WM3-C |
WM3x |
WM3-C |
WM3x |
WM3-C |
|
1-Feb-19 |
9.3 |
9.6 |
11.7 |
21.2 |
7.0 |
28.5 |
4-Feb-19 |
9.7 |
9.0 |
3.7 |
2.6 |
<2 |
<2 |
8-Feb-19 |
9.2 |
9.2 |
4.6 |
18.5 |
2.0 |
9.5 |
11-Feb-19 |
9.8 |
9.3 |
3.5 |
4.8 |
2.0 |
2.0 |
13-Feb-19 |
9.3 |
9.2 |
14.2 |
13.4 |
9.5 |
9.0 |
15-Feb-19 |
9.4 |
9.6 |
9.9 |
13.2 |
5.0 |
6.5 |
18-Feb-19 |
9.0 |
9.2 |
7.9 |
30.6 |
8.5 |
28.0 |
20-Feb-19 |
8.3 |
8.7 |
13.8 |
33.0 |
12.5 |
38.5 |
22-Feb-19 |
8.7 |
9.0 |
25.5 |
26.3 |
30.0 |
29.0 |
25-Feb-19 |
9.9 |
9.1 |
13.3 |
8.2 |
12.5 |
9.0 |
27-Feb-19 |
9.2 |
8.9 |
24.1 |
27.4 |
10.5 |
16.0 |
Table 6-5 Action
and Limit (A/L) Levels Exceedance Recorded
Location |
Dissolved Oxygen |
Turbidity |
Suspended Solids |
Total Exceedance |
Project Related
exceedance |
|||||
AL |
LL |
AL |
LL |
AL |
LL |
AL |
LL |
AL |
LL |
|
WM1 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
WM2A(a) |
0 |
0 |
0 |
1 |
0 |
1 |
0 |
2 |
0 |
0 |
WM2B |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
WM3x |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
WM4 |
0 |
0 |
0 |
1 |
0 |
1 |
0 |
2 |
0 |
# |
No of Exceedance |
0 |
0 |
0 |
2 |
0 |
2 |
0 |
4 |
0 |
# |
Remark: # Investigation is underway by ET.
6.2.4
In this Reporting Period, a total of four (4)
Limit Level exceedances, namely two (2) Limit Level exceedances of turbidity and two (2) Limit
Level exceedances of Suspended Solids were recorded for the Project and they
are summarized in Table 6-5.
Investigation reports for water quality exceedances have been conducted
by ET accordingly. The
investigation for exceedance recorded at WM2A(a) on 8 February 2019 was not
related to the work under the project.
The investigation report for exceedance recorded at WM4 on 25 February
2019 is underway by ET.
6.2.5
NOE was issued to relevant parties upon
confirmation of the monitoring result.
The investigation results and summary of exceedances are summarized in Table
6-6. The details of the
completed investigation reports for the exceedances are attached in Appendix
N.
Table 6-6 Summary
of Water Quality Exceedance in the Reporting Period
Date of Exceedance |
Location |
Exceeded Parameter |
Cause of Water Quality Exceedance In Brief |
8 February 2019 |
WM2A(a) |
Turbidity
& SS |
In our investigation, CCKJV has properly implemented the water quality
mitigation measures especially for slope adjacent to the stream. There were no construction activities
carried out on 8 February and no discharge and runoff made from the site was
observed. The construction site
was general in order and no adverse impact was recorded during site
inspection. It is considered that
the exceedances were unlikely due to the work under the project. |
25 February 2019 |
WM4 |
Turbidity
& SS |
The investigation report is still underway by ET. |
7.1.1
Ecology monitoring for woodland
compensation was shall be conducted at bi-monthly interval for the first year and the
monitoring frequency would be reduced to quarterly from the second year.
7.1.2
The Ecology Monitoring for period of December 2018
to February 2019 was carried out on 25th and 26th
February 2019 by transects inspection and quadrat monitoring. The Quarterly Ecological Monitoring
Report will be submitted separately to the EM&A Report.
8.1.1
Waste management was carried out in
accordance with the Waste Management Plan (WMP) for each contract.
8.2.1
All types of waste arising from the
construction work are classified into the following:
l Construction
& Demolition (C&D) Material;
l Chemical
Waste;
l General
Refuse; and
l Excavated
Soil.
8.2.2
The quantities of waste for disposal in this Reporting
Period are summarized in Tables 8-1 and 8-2 and the Monthly
Summary Waste Flow Table is shown in Appendix L. Whenever possible, materials were reused
on-site as far as practicable.
Table 8-1 Summary
of Quantities of Inert C&D Materials for the Project
Type of Waste |
Contract 2 |
Contract 3 |
Contract 4 |
Contract 6 |
Contract 7 |
Contract SS C505 |
Total Qty. |
||||||
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
||
C&D Materials (Inert) (in '000m3) |
1.5710 |
-- |
4.659 |
-- |
0 |
-- |
17.959 |
-- |
2.035 |
-- |
4.609 |
-- |
30.833 |
Reused in this Contract (Inert) (in '000 m3) |
0 |
-- |
0 |
-- |
0 |
-- |
0 |
-- |
0 |
-- |
0.150 |
-- |
0.15 |
Reused in other Contracts/ Projects (Inert) (in '000 m3) |
0.2000 |
Recycling facility as approved alternative
site # |
0 |
-- |
0 |
-- |
0.280 |
Reused at NENT # |
1.386 |
CEDD Contract - YL/2017/03 # |
0 |
-- |
1.866 |
Disposal as Public Fill (Inert) (in '000 m3) |
1.3710 |
Tuen Mun 38 |
3.818 |
Tuen Mun 38 |
0 |
-- |
11.168 |
Tuen Mun 38 |
0.649 |
Tuen Mun 38 |
3.861 |
TKO 137 |
20.867 |
# Approved alternative site
Table 8-2 Summary
of Quantities of C&D Wastes for the Project
Type of Waste |
Contract 2 |
Contract 3 |
Contract 4 |
Contract 6 |
Contract 7 |
Contract SS C505 |
Total Quantity |
||||||
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
Qty. |
Disposal location |
||
Recycled Metal (¡¥000kg) # |
0 |
-- |
0 |
- |
0 |
-- |
0 |
-- |
1.2 |
Licensed collector |
0 |
-- |
1.2 |
Recycled
Paper / Cardboard Packing (¡¥000kg) # |
0 |
-- |
0 |
- |
0 |
- |
0 |
-- |
0.1 |
Licensed collector |
0.410 |
Licensed collector |
0.51 |
Recycled Plastic (¡¥000kg) # |
0 |
-- |
0 |
- |
0 |
-- |
0 |
-- |
0.001 |
Licensed collector |
2.660 |
Licensed collector |
2.661 |
Chemical Wastes (¡¥000kg) # |
0 |
-- |
0 |
- |
0 |
-- |
0 |
-- |
0 |
-- |
0 |
-- |
0 |
General Refuses (¡¥000m3) |
0.1060 |
NENT |
0.075 |
NENT |
0 |
-- |
0.278 |
NENT |
0.1 |
NENT |
1.157 |
NENT |
1.716 |
Remark #: Unit of recycled metal, recycled paper/ cardboard packing and recycled plastic under Contract 3 was in (¡¥000m3) while the unit of chemical wastes for Contract 3 was in (¡¥m3).
9.1.1
According to the approved EM&A Manual,
the environmental site inspection shall be formulation by ET Leader. Weekly environmental site inspections should
carry out to confirm the environmental performance.
Contract 2
9.2.1
In the Reporting Period, joint site
inspection for Contract 2 to evaluate the site environmental performance has been
carried out by the RE, IEC, ET and the Contractor on
1, 8, 15 and 21 February 2019.
No non-compliance was noted.
9.2.2
The findings / deficiencies of Contract
2 that observed during the weekly site inspection are listed in Table
9-1.
Table 9-1 Site
Observations for Contract 2
Date |
Findings /
Deficiencies |
Follow-Up Status |
1 February 2019 |
Silty water was observed at discharge
point (South Portal).The Contractor should properly maintain the wastewater treatment
facility and ensure the discharge comply to the discharge license
requirement. |
The wastewater was properly treated. |
8 February 2019 |
No adverse environmental issue was
observed. |
NA |
15 February 2019 |
Free standing chemical container was
observed on the ground at South Portal. The Contractor should provide drip
tray for any chemical containers to prevent leakage. |
Drip tray was provided for chemical
container. |
21 February 2019 |
No adverse environmental issue was
observed. |
NA |
Contract 3
9.2.3
In the Reporting Period, joint site
inspection for Contract 3 to evaluate the site environmental performance has
been carried out by the RE, IEC, ET and the Contractor on 8, 14, 20 and 28
February 2019. No non-compliance was noted.
9.2.4
The findings / deficiencies of Contract
3 that observed during the weekly site inspection are listed in Table
9-2.
Table 9-2 Site
Observations for Contract 3
Date |
Findings /
Deficiencies |
Follow-Up Status |
8 February 2019 |
No adverse environmental issue was
observed. |
NA |
14 February 2019 |
The Contractor was reminded to maintain
all site exit clean and tidy and ensure no muddy water present at the public
road. |
Not required for reminder. |
20 February 2019 |
No adverse environmental issue was
observed. |
NA |
28 February 2019 |
No adverse environmental issue was
observed. |
NA |
Contract 4
9.2.5
In the Reporting Period, joint site
inspection for Contract 4 to evaluate
the site environmental performance has been carried out by the RE, IEC, ET and
the Contractor on 1, 8, 15, 22 and 25 February 2019.
No non-compliance was noted.
9.2.6
The findings / deficiencies of Contract
4 that
observed during the weekly site inspection are listed in Table 9-3.
Table 9-3 Site
Observations for Contract 4
Date |
Findings /
Deficiencies |
Follow-Up Status |
1 February 2019 |
No adverse environmental issue was
observed. |
NA |
8 February 2019 |
No adverse environmental issue was
observed. |
NA |
15 February 2019 |
No adverse environmental issue was
observed. |
NA |
22 February 2019 |
No adverse environmental issue was
observed. |
NA |
25 February 2019 |
No adverse environmental issue was
observed. |
NA |
Contract 6
9.2.7
In the Reporting Period, joint site
inspection for Contract 6 to evaluate the site environmental performance has
been carried out by the RE, IEC, ET and the Contractor on 8, 14, 21 and 28
February 2019. No non-compliance was noted.
9.2.8
The findings / deficiencies of Contract
6 that observed during the weekly site inspection are listed in Table
9-4.
Table 9-4 Site
Observations for Contract 6
Date |
Findings /
Deficiencies |
Follow-Up Status |
8 February 2019 |
No adverse environmental issue was
observed. |
NA |
14 February 2019 |
No adverse environmental issue was
observed. |
NA |
21 February 2019 |
The Contractor was reminded to maintain
all site exit clean and tidy. |
Not
required for reminder. |
28 February 2019 |
No adverse environmental issue was
observed. |
NA |
Contract SS C505
9.2.9
In the Reporting Period, joint site
inspection for Contract SS C505 to evaluate the site environmental performance
has been carried out by the RE, ET and the Contractor on 4, 13, 20 and 27
February 2019 in which IEC joined the
site inspection on 20 February 2019. No non-compliance was noted.
9.2.10
The findings / deficiencies of Contract
SS C505 that observed during the weekly site inspection are listed in Table
9-5.
Table 9-5 Site
Observations for Contract SS C505
Date |
Findings /
Deficiencies |
Follow-Up Status |
4 February 2019 |
The Contractor was reminded to provide
drip tray for any chemical container. The Contractor was reminded to dispose and
replace broken water barriers to prevent water accumulation. |
Not required for reminder. Not required for reminder. |
13 February 2019 |
Open stockpile was observed at Bridge 2. The
contractor should cover it with tarpaulin sheet to prevent dust emission. |
Open stockpile was covered with tarpaulin
sheet. |
20 February 2019 |
The Contractor was reminded to remove
stagnant water regularly after rainstorm The Contractor was reminded to maintain
good housekeeping on site. |
NA |
27 February 2019 |
Free standing chemical containers were
observed near building 1. The Contractor should provide drip tray for any
chemical containers to prevent leakage. |
Chemical containers were removed. |
Contract 7
9.2.11
In the Reporting Period, joint site
inspection for Contract 7 to evaluate the site environmental performance has
been carried out by the RE, IEC, ET and the Contractor on 1, 8, 15, 22 and
26 February 2019. No non-compliance was noted.
9.2.12
The findings / deficiencies of Contract
7 that observed during the weekly site inspection are listed in Table
9-6.
Table 9-6 Site
Observations for Contract 7
Date |
Findings /
Deficiencies |
Follow-Up Status |
1 February 2019 |
General refuse was observed on the ground
near bridge A. The Contractor should dispose the waste regularly and maintain
good housekeeping on the site. The Contractor was reminded to maintain
generator function properly. |
The general refuse was removed and
disposed properly. Not required for reminder. |
8 February 2019 |
The Contractor was reminded to maintain
generator function properly. The Contractor was reminded to cover the
stockpile to avoid dust emission. |
Not required for reminder. Not required for reminder. |
15 February 2019 |
No adverse environmental issue was
observed. |
NA |
22 February 2019 |
The Contractor was reminded to remove
stagnant water to prevent accumulation. |
Not required for reminder. |
26 February 2019 |
No adverse environmental issue was
observed. |
NA |
9.2.13
General housekeeping such as daily site
tidiness and cleanliness should be
maintained for all Contracts.
Furthermore, the Contractors were reminded to implement Waste Management
Plan of the Project.
10.1.1
In
the Reporting Period, two (2)
documented environmental complaints were received for Contract 3 regarding the construction
noise and site cleanliness issues. No summons
and prosecution under the EM&A
Programme was lodged for all Contracts. The status
of the investigation report in previous months is summarized below.
Date of complaint |
Complaint Detail |
Investigation Status |
29 November 2018 (Last Reporting
Period) |
A public Complaint was received on 29 Nov 2018 and referred to ET in
Dec 2018 regarding the emission of dust and muddy road along the Lin Ma Hang
Road in between Tsung Yuen Ha Village and Ta Kwu Ling police station.
(Contract SS C505, Contract 6 and Contract 7) |
In our investigation, the Contractors have implemented dust control
measures as such provide the wheel washing facilities at site exit and
properly maintained cleanliness of site exit and adjoin roads. No cumulated muddy water and mud
trails were observed at the site exit under Contract 6, Contract 7 and
Contract SS C505 and adjoined LMH Road during our inspections. Since there were many other heavy
vehicles apart from LT/HYW Project using LMH Road particularly between Ta Kwu
Ling Police Station and Chuk Yuen Village and certain number of unknown exit
sites without proper management along LMH Road, it is considered that the
complaint was not related to the works under the Project. The IR without comment from IEC was shown in Appendix O. |
30 January 2019 (Last
Reporting Period) |
A complaint was received
by EPD on 30 January 2019 about emission of construction dust from Chun Wo
construction site near Food and Environmental Hygiene Department (FEHD)'s Refuse
Collection Point (RCP) near Bridge Pier ID TP-60. (Contract 3) |
In our investigation, the Contractor has implemented dust control
measures such as providing adequate wheel washing at site exit, road cleaning
by water tanker for entire site and covered stockpile when not in used. There were no Record of Inspection
(yellow/ pink inspection form) issued by EPD and no non-compliance observed
during site inspection. It
is considered that the complaint was not related to the works under the
Contract work. The IR without comment from IEC was shown in Appendix O. |
28 January 2019 (received
by ET on 14 Feb 2019) |
A public complaint was
received by EPD on 28 January 2019 about noise disturbance generated by the
construction works at 8pm at Kau Lung Hang claiming from Chun Wo¡¦s
construction site (Contract 3). |
As confirmed by Chun Wo,
there was no construction activity after 18:00 on 28 January 2019. EPD had
also conducted surprise check after the complaint and no non-compliance
was observed. It is considered that the complaint is not valid to
Contract 3. The IR without comment from IEC was shown in Appendix O. |
21 February 2019 |
A public complaint was received
by 1823 on 21 Feb 2019 about cleanliness of Chun Wo construction site near
Yuen Leng concerning on water spraying around the site area causing mud and
muddy water rush out from the site to public road. (Contract 3). |
The draft IR was submitted to IEC on 11 Mar 2019. IEC issued comment
13 Mar and the IR is pending revised by ET. |
10.1.2
The statistical summary of environmental complaint is
presented in Tables 10-1, 10-2 and 10-3.
Table 10-1 Statistical
Summary of Environmental Complaints
Reporting Period |
Contract No |
Environmental
Complaint Statistics |
Project related
complaint |
||
Frequency |
Cumulative |
Complaint Nature |
|||
19 May 2014 ¡V 31 January 2019 |
Contract 2 |
0 |
37 |
(19)Water Quality (10) Dust (5) Noise (1) dust & noise (1) waste
management (1) Water quality and dust |
(7) water quality (3) dust (1) noise |
06 Nov 2013 ¡V 31 January 2019 |
Contract 3 |
0 |
7 |
(3) Dust (3) Water quality (1) Noise |
0 |
16 Aug 2013 ¡V 31 January 2019 |
Contract 4 |
0 |
0 |
(3) Dust (1) Noise |
0 |
16 Aug 2013 ¡V 31 January 2019 |
Contract 6 |
0 |
45 |
(24) Water Quality (12) Dust (3) Noise (1) Nuisance (1) Noise and dust (3) Water quality and dust (1) Water quality and noise |
(8) water quality (3) dust (1) nuisance (1) water quality and dust (1) water quality and noise |
15 Feb 2016 ¡V 31 January 2019 |
Contract 7 |
0 |
4 |
(1) Noise (3) Water quality and dust |
(1) water quality and dust |
16 Aug 2013 ¡V 31 January 2019 |
SS C505 |
0 |
7 |
(1) Noise (2) dust (3) Water quality and dust (1) Water quality |
(1) water quality and dust |
1 ¡V 28 February 2019 |
Contract 2 |
0 |
37 |
(19)Water Quality (10) Dust (5) Noise (1) dust & noise (1) waste
management (1) Water quality and dust |
NA |
Contract 3 |
2 |
9 |
(3) Dust (3) Water quality (2) Noise (1) site
cleanliness (dust & water quality) |
NA (#) |
|
Contract 4 |
0 |
0 |
NA |
NA |
|
Contract 6 |
0 |
45 |
(24) Water Quality (12) Dust (3) Noise (1) Nuisance (1) Noise and dust (3) Water quality and dust (1) Water quality and noise |
NA |
|
Contract 7 |
0 |
4 |
(1) Noise (3) Water quality and dust |
NA |
|
SS C505 |
0 |
7 |
(1) Noise (2) dust (3) Water quality and dust (1) Water quality |
NA |
Remark: (#) the complaint case was under investigation.
Table 10-2 Statistical
Summary of Environmental Summons
Reporting Period |
Contract No |
Environmental
Summons Statistics |
||
Frequency |
Cumulative |
Complaint Nature |
||
19 May 2014 ¡V 31 January 2019 |
Contract 2 |
0 |
1 |
contravening the Water Pollution Control (General)
Regulations |
06 Nov 2013 ¡V 31 January 2019 |
Contract 3 |
0 |
0 |
NA |
16 Aug 2013 ¡V 31 January 2019 |
Contract 5 |
0 |
0 |
NA |
16 Aug 2013 ¡V 31 January 2019 |
Contract 6 |
0 |
0 |
NA |
15 Feb 2016 ¡V 31 January 2019 |
Contract 7 |
0 |
0 |
NA |
16 Aug 2013 ¡V 31 January 2019 |
SS C505 |
0 |
0 |
NA |
1 ¡V 28 February 2019 |
Contract 2 |
0 |
1 |
NA |
Contract 3 |
0 |
0 |
NA |
|
Contract 4 |
0 |
0 |
NA |
|
Contract 6 |
0 |
0 |
NA |
|
Contract 7 |
0 |
0 |
NA |
|
SS C505 |
0 |
0 |
NA |
Table 10-3 Statistical
Summary of Environmental Prosecutions
Reporting Period |
Contract No |
Environmental
Prosecutions Statistics |
||
Frequency |
Cumulative |
Complaint Nature |
||
19 May 2014 ¡V 31 January 2019 |
Contract 2 |
0 |
1 |
contravening the Water Pollution Control
(General) Regulations |
06 Nov 2013 ¡V 31 January 2019 |
Contract 3 |
0 |
0 |
NA |
16 Aug 2013 ¡V 31 January 2019 |
Contract 5 |
0 |
0 |
NA |
16 Aug 2013 ¡V 31 January 2019 |
Contract 6 |
0 |
0 |
NA |
15 Feb 2016 ¡V 31 January 2019 |
Contract 7 |
0 |
0 |
NA |
16 Aug 2013 ¡V 31 January 2019 |
SS C505 |
0 |
0 |
NA |
1 ¡V 28 February 2019 |
Contract 2 |
0 |
1 |
NA |
Contract 3 |
0 |
0 |
NA |
|
Contract 4 |
0 |
0 |
NA |
|
Contract 6 |
0 |
0 |
NA |
|
Contract 7 |
0 |
0 |
NA |
|
SS C505 |
0 |
0 |
NA |
11.1.1
The environmental mitigation measures that
recommended in the Implementation Schedule for Environmental Mitigation Measures
(ISEMM) in the approved EM&A Manual covered the issues of dust, noise,
water and waste and they are summarized presented in Appendix M.
11.1.2
All contracts under the Project shall be
implementing the required environmental mitigation measures according to the
approved EM&A Manual as subject to the site condition. Environmental mitigation measures
generally implemented by Contracts 2, 3, 4, 5, 6, 7 and Contract SS C505 in this Reporting Period are summarized in
Table
11-1.
Table 11-1 Environmental
Mitigation Measures
Issues |
Environmental
Mitigation Measures |
Water Quality |
¡P
Wastewater to be treated by the wastewater treatment facilities i.e.
sedimentation tank or similar facility before discharge. |
Air Quality |
¡P
Maintain damp / wet surface on access road ¡P
Low vehicular speed within the works areas. ¡P
All vehicles must use wheel washing facility before off site ¡P
Sprayed water during breaking works ¡P
A cleaning truck was regularly performed on
the public road to prevent fugitive dust emission |
Noise |
¡P
Restrain operation time of plants from 07:00 to 19:00 on any working
day except for Public Holiday and Sunday. ¡P
Keep good maintenance of plants ¡P
Place noisy plants away from residence or school ¡P
Provide noise barriers or hoarding to enclose the noisy plants or
works ¡P
Shut down the plants when not in used. |
Waste and Chemical Management |
¡P
On-site sorting prior to disposal ¡P
Follow requirements and procedures of the ¡§Trip-ticket System¡¨ ¡P
Predict required quantity of concrete accurately ¡P
Collect the unused fresh concrete at designated locations in the
sites for subsequent disposal |
General |
¡P
The site was generally kept tidy and clean. |
11.2.1
As advised by the ER, the construction works under
Contract 5 was substantially completed on 31 August 2016. Construction activities for other
Contracts in the coming month are listed below:
Contract 2
Mid-Vent Portal |
Defect rectification for
Ventilation building
Construction of flexible barrier
External reinstatement and
landscaping works
Testing and Commissioning for
E&M facilities |
North Portal |
Construction slip road and
permanent drainage
Road paving and cladding
installation inside the tunnel
External reinstatement and
landscaping works
Defect rectification for
Ventilation building
Testing and Commissioning for
E&M facililties |
South Portal |
Construction slip road and
permanent drainage
Road paving and cladding
installation inside the tunnel
Defect rectification for
Ventilation building
Testing and Commissioning for
E&M facililties
Construction of flexible barrier
External backfilling,
reinstatement and landscaping works.
Dismantling the concrete pier of
the temporary steel bridge |
Admin Building |
Defect rectification
External reinstatement and
landscaping works |
Contract 3
Cable detection and trial trenches
Remaining works on new Footbridge
Noise barrier construction
Road pavement works
Water main laying works (on Grade)
Installation of Noise barrier panel (on Grade)
Road Drainage Works
Bitumen paving on bridge deck
Construction of Pavilion and Pai Lau
Construction of retaining wall
Landscaping works
Contract 4
T&C installation at Admin Building
T&C at tunnel
Panel installation at Cheung Shan Tunnel
Contract 6
Bridge
construction
Tunnel Works
Sewage Treatment Plant Construction
Tunnel Ventilation Building Construction
Slip Road/At-grade Road/Periphery Road
Construction
Contract 7
Noise barrier construction at Bridge D and
E
Parapet installation at Bridge A & E
Drainage pipe laying at Bridge A, B, D and
E
Green roof system at Roof of Bridge C
Boundary Fence at Roof of Bridge C
Street lighting and CCTV installation at
perimeter road
Shenzhen River reinstatement
Landscape Softwork
Contract SS C505
Passenger Terminal Building (PTB) Structure
Works - G/F Plant Rooms Structure Works, G/F Backfiling & Drainage, Under
Ground Utilities, Fence Wall and On Grade Slab
PTB - ABWF Works & MEP Installation -
Front/Back of House Area, External Staircases, External Staircases, Hall Block
External Façade, Southern Entrance Construction, Major Plant Rooms & EAC
Doors
PTB - External Works incl. Building 21-24,
M/F External Wall (Ewall), Roof & Upper Roof Roofing Works, Podium Coach Canopy,
21&22 (C&PC KIOSKS) & 23&24 (PC Examination Building &
MXRVSS), Podium Open Area & Ambulance Canopy / Glazed Canopy
Bridge C Integrated ABWF and MEP
Installation Works (C7 Portion) - Arrival & Departure Hall, Staircases,
Test & Commissioning
Bldg 1 - C&ED Detector Dog Base Phase 1
- Integrated ABWF & MEP Works at G/F, R/F & External
Bldg 2 - HKPF Building and Observation
Tower Phase 1 - External Works, Integrated ABWF & MEP Works at G/F to 4/F,
Observation Tower (incluidng Lift) & External Works
Bldg 3 - Fire Station and Drill Tower Phase
1 - External Works, Integrated ABWF & MEP Works at G/F to UR/F & Drill
Tower
Bldg 4 - Cargo Examination Building
(Inbound) Phase 1 - External Works at G/F under Steel Roof, Integrated ABWF
& MEP Works at G/F to R/F & Loading Dock
Bldg 5 - Cargo Examination Building
(Outbound) Phase 2 - External Works at G/F under Steel Roof, Integrated ABWF
& MEP Works at G/F to R/F & Loading Dock
Bldg 6 - Fixed X-ray Vehicle Inspection
System (FXRVIS) Buildings (Inbound) Phase 1 - External Works (FXI Fence Wall),
Integrated ABWF & MEP Works at G/F to R/F
Bldg 7 - Fixed X-ray Vehicle Inspection
System (FXRVIS) Buildings (Outbound) Phase 2 - External Works, Integrated ABWF
& MEP Works at G/F to 1/F & Roof works
Bldg 8 - MXRVSS (Inbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & R/F
Bldg 9 - MXRVSS (Outbound) Phase 2 -
Structure Works at G/F, Integrated ABWF and MEP Works at G/F & Envelope
Bldg 10 - GV Kiosk (Inbound) Phase 2 -
On-Grade Slab, Integrated ABWF and MEP Works at G/F & R/F
Bldg 11 - GV Kiosk (Outbound) Phase 2 -
On-Grade Slab, Integrated ABWF & MEP Works at G/F & R/F
Bldg 12 - Public Toilets (Inbound) Phase 2
- Integrated ABWF and MEP Works at G/F & Envelope
Bldg 13 - Public Toilets (Outbound) Phase 2
- Integrated ABWF and MEP Works at G/F & R/F
Bldg 14 - Disinsection Facilities (Inbound)
Phase 2 - Integrated ABWF & MEP Works at G/F & Envelope
Bldg 15 - Disinsection Facilities
(Outbound) Phase 2 - Substructure Works, Integrated ABWF & MEP Works at G/F
& Envelope
Bldg 16 - Weigh Station Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 17 - EUVSS & Monitoring Room Phase
2 - Structure Works, Integrated ABWF & MEP Works at G/F & R/F
Bldg 18 - Refuse Collection Point Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 25 - Traffic Control Office (Inbound)
Phase 2 - Integrated ABWF and MEP Works at G/F & Envelope
Bldg 26 - Traffic Control Office (Outbound)
Phase 2 - Integrated ABWF and MEP Works at G/F & Envelope
Bldg 27 - Inspection Post Phase 2 - Integrated
ABWF and MEP Work at G/F & Envelope
Bldg 28 - Guard Booth (Inbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 29 - Guard Booths (Vehicle Detention
Area) Phase 2 - Integrated ABWF and MEP Works at G/F & Envelope
Bldg 30 - Guard Booth (Outbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 31 - Guard Booth (Inbound) Phase 2 -
Integrated ABWF and MEP Works at G/F & Envelope
Bldg 32/33/34/35 - Steel Canopy 1 to 4
Phase 2 - Integrated ABWF and MEP Works
Bldg 36 - Fire Hydrant Tank & Pump Room
Phase 1 - Integrated ABWF and MEP Works at R/F
Bldg 37/38/39 - Elevated Walkways (E1, E2
& E3) Phase 2 - Structures Works, ABWF and BS Works
Bldg 40 - Elevated Walkway E4 Phase 2 -
Structures Works, ABWF and BS Works
Vehicular Bridges 1 & 4 Phase 3 -
Retaining walls, Road and Finishes Works
Vehicular Bridges 2, 3 & 5 Phase 3 -
Road and Finishes Works
External Works - Water Meter Room
Connection (inbound & outbound)
External Utilities Works - UU works for
phase 2 FS inspection & DSD inspection
External Road & Pavement Works - for
inbound - Phase 1 FS inspection & for Phase 2 FS inspection
External Landscape - Inbound & Outbound
area
"Testing & Commissioning (T&C)
and FSD/SCCU Inspection Phase 1
T&C - FSD, HKPF, CBI, FXI, DOG &
Bldg 36
FS Inspection - FSD Cert. Issue & Final O&M
Manual, Test Report
SCCU Inspection & Handover "
"Testing & Commissioning (T&C)
and FSD/SCCU Inspection Phase 2
T&C - CBO, FXO, Inbound & Outbound
Groups
FS Inspection - EVA, CBO & FXO, Inbound &
Outbound Groups"
"Testing & Commissioning (T&C)
and FSD/SCCU Inspection Phase 3
T&C - EVA & PTB"
11.3.1
Key
issues to be considered in the coming month for Contracts 2, 3, 4, 6, 7 and SS C505 include:
Implementation of control measures for
rainstorm;
Regular clearance of stagnant water during
wet season;
Implementation of dust suppression measures
at all times;
Potential wastewater quality impact due to
surface runoff;
Potential fugitive dust quality impact due from
the dry/loose/exposure soil surface/dusty material;
Disposal of empty engine oil containers
within site area;
Ensure dust suppression measures are
implemented properly;
Sediment catch-pits and silt removal
facilities should be regularly maintained;
Management of chemical wastes;
Discharge of site effluent to the nearby
wetland, stockpiling or disposal of materials, and any dredging or construction
area at this area are prohibited;
Follow-up of improvement on general waste
management issues; and
Implementation of construction noise
preventative control measures
12.1.1
This is the 67th monthly EM&A report presenting the monitoring results and inspection
findings for the Reporting Period from 1 to 28 February 2019.
12.1.2
For
air quality monitoring, no 1-hour TSP and 24-hour TSP monitoring results triggered the Action /Limit Level was recorded.
12.1.3
In the Reporting Period, no construction
noise measurement results that exceeded the Limit Level were recorded. Moreover, no valid noise
complaint (which
triggered an Action Level)
exceedance was recorded.
12.1.4
In this Reporting Period, four (4) Limit
Level exceedances, namely two (2) LL of turbidity and two (2) LL of
Suspended Solids were recorded for the Project. The investigation
report for exceedance recorded at WM2A(a) on 8 February 2019 revealed that
exceedance was not related to the work under the project. The investigation report for exceedance
recorded at WM4 on 25 February 2019 is underway by ET and the investigation result
will be presented next month.
12.1.5
In this Reporting Period, two (2) documented environmental complaints were received in
relation to Contract 3. The first complaint was
received on 28 Jan 2019 regarding noise disturbance from C3¡¦s construction site
at 8pm. The C3¡¦s Contractor confirmed that there was no construction activity
after 18:00 on the concerned date. Investigation was conducted by ET and
the IR revealed that the complaint was not valid to the Project. The second complaint was received on 21
Feb 2019 about cleanliness of Chun Wo construction site near Yuen Leng
concerning on water spraying around the site area causing mud and muddy water
rush out from the site to public road. Investigation is underway by ET.
12.1.6
No
summons and prosecution under the EM&A Programme was lodged in the Reporting Period.
12.1.7
During
the Reporting Period, weekly joint site inspection by the RE, IEC, ET with the relevant
Main-contractor were carried out for Contracts 2, 3, 4, 6 and 7 in accordance with the EM&A Manual
stipulation. For Contract SS C505, weekly
joint site inspection was carried out
by the RE, IEC, ET
and main-contractor
whereas IEC performed
monthly site inspection. No non-compliance observed during the
site inspection.
12.2.1
As wet
season is approaching, preventive measures for muddy water or other water
pollutants from site surface flow to local stream such as Kong Yiu Channel, Ma
Wat Channel, Ping Yuen River, Kwan Tei River or public area should be properly
maintained. The Contractors should
paid special attention on water quality mitigation measures and fully implement
according ISEMM of the EM&A Manual.
12.2.2
In
addition, all effluent discharge shall be ensure to fulfill Technical
Memorandum of Effluent Discharged into Drainage and Sewerage Systems, inland
and Coastal Waters criteria or discharge permits stipulation.
12.2.3
Construction
noise would be a key environmental issue during construction work of the
Project. Noise mitigation measures
such as using quiet plants should be implemented in accordance with the
EM&A requirement.
12.2.4
Since
most of construction sites under the Project are located adjacent to villages,
the Contractors should fully implement air quality mitigation measures to
reduce construction dust emission.
12.2.5
Furthermore, daily cleaning and weekly tidiness shall be properly
performed and maintained. In addition, mosquito control should be kept to prevent mosquito breeding on site.
