D

epartment

Remark:
	1) Density of C&D material to be	2.2	metric ton/m3	3) Density of Spent Oil to be	0.88	metric ton/m3
	2) Density of General Refuse to be	1.6	metric ton/m3

Name of Department : CEDD Contract No./ Work Order No. : CV/2012/08

Appendix I - Monthly Summary Waste Flow Table for 2016

(All quantities shall be rounded off to 3 decimal places)

Month	Actual Quantities of Inert C&D Materials Generated / Imported (in '000 m3)							Actual Quantities of Other C&D Materials / Wastes Generated
Month	Total Quantities Generated [a+b+c+d)	Broken Concrete (including rock for recycling into aggregates) (a)	Reused in the Contract (b)	Reused in Other Projects (c)	Disposed as Public Fill (d)	Imported C&D Material	Metal (in '000kg)	Paper/ Cardboard Packaging (in '000kg)	Plastic (bottles/containers, plastic sheets/ foams from package material) (in '000kg)	Chemical Waste (in '000kg)	Others (e.g. General Refuse etc.) (in '000m3)
January	74.4242	0.0000	0.6482	32.5036	41.2724	0.5518	0.0000	0.0000	0.0000	0.8800	0.1247
February	0.0000
March	0.0000
April	0.0000
May	0.0000
June	0.0000
Half-year total	74.4242	0.0000	0.6482	32.5036	41.2724	0.5518	0.0000	0.0000	0.0000	0.8800	0.1247
July	0.0000
August	0.0000
September	0.0000
October	0.0000
November	0.0000
December	0.0000
Yearly Total	74.4242	0.0000	0.6482	32.5036	41.2724	0.5518	0.0000	0.0000	0.0000	0.8800	0.1247

(All quantities shall be rounded off to 3 decimal places)

Year	Actual Quantities of Inert C&D Materials Generated / Imported (in '000 m3)							Actual Quantities of Other C&D Materials / Wastes Generated
Year	Total Quantities Generated [a+b+c+d)	Broken Concrete (including rock for recycling into aggregates) (a)	Reused in the Contract (b)	Reused in Other Projects (c)	Disposed as Public Fill (d)	Imported C&D Material	Metal (in '000kg)	Paper/ Cardboard Packaging (in '000kg)	Plastic (bottles/containers, plastic sheets/ foams from package material) (in '000kg)	Chemical Waste (in '000kg)	Others (e.g. General Refuse etc.) (in '000m3)
2013	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000
2014	425.4406	0.0000	2.7362	376.3945	46.3099	5.6245	3.2100	0.4390	0.0070	10.8800	2.2609
2015	570.9459	0.0000	20.8159	543.2162	6.9138	4.5492	14.1300	3.9220	1.5000	16.1920	1.1696
2016	74.4242	0.0000	0.6482	32.5036	41.2724	0.5518	0.0000	0.0000	0.0000	0.8800	0.1247
2017
2018
Total	1070.8107	0.0000	24.2003	952.1144	94.4961	10.7255	17.3400	4.3610	1.5070	27.9520	3.5552

Remark:
	1) Density of C&D material to be	2.2	metric ton/m3	3) Density of Spent Oil to be	0.88	metric ton/m3
	2) Density of General Refuse to be	1.6	metric ton/m3

itectural S

Monthly Summary Waste Flow Table for 2015 (year)

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in m3)	(in '000m3)
Jan	3.864	0.105	0.648	0.000	3.216	0.118	0.000	0.000	0.000	0.040	0.080
Feb	2.429	0.049	1.518	0.000	0.911	0.100	0.000	0.000	0.003	0.900	0.070
Mar	3.713	0.029	0.270	0.000	3.443	0.100	0.000	0.000	0.006	0.000	0.080
Apr	3.597	0.115	2.308	0.000	1.289	0.090	0.003	0.000	0.000	0.000	0.065
May	1.357	0.197	0.108	0.000	1.249	0.100	0.000	0.000	0.012	0.000	0.065
Jun	2.515	0.053	0.840	0.000	1.675	0.125	0.000	0.000	0.030	0.800	0.060
Sub-total	17.475	0.547	5.692	0.000	11.783	0.633	0.003	0.000	0.051	1.740	0.420
Jul	1.177	0.030	0.351	0.000	0.826	1.564	0.000	0.000	0.000	0.000	0.065
Aug	1.966	0.164	0.294	0.000	1.672	0.956	0.002	0.000	0.001	0.000	0.130
Sep	2.092	0.027	0.264	0.000	1.828	1.141	0.000	0.000	0.001	0.000	0.115
Oct	2.462	0.381	1.500	0.000	0.962	0.226	0.000	0.000	0.001	0.000	0.125
Nov	2.990	0.709	1.200	0.000	1.790	0.066	0.001	0.000	0.000	0.000	0.130
Dec	3.158	0.174	1.600	0.000	1.558	0.259	0.000	0.000	0.001	0.600	0.145
Total	31.320	2.033	10.901	0.000	20.419	4.846	0.006	0.000	0.055	2.340	1.130

Apr

Assume the density of rock and broken concrete is 2.5 ton/m³.
Assume each truck of C&D wastes is 5m³.
The inert C&D materials except slurry and bentonite are disposed at Tuen Mun 38.
The slurry and bentonite are disposed at Tseung Kwun O 137.
The non-inert C&D wastes are disposed at NENT.
Assume the density of metal is 7,850 kg/m³.

Name of Department: CEDD Contract No.: CV/2012/09

Monthly Summary Waste Flow Table for 2016 (year)

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in m3)	(in '000m3)
Jan	2.430	0.253	0.030	0.000	2.400	0.799	0.001	0.000	0.000	0.000	0.115
Feb
Mar
Apr
May
Jun
Sub-total	2.430	0.253	0.030	0.000	2.400	0.799	0.001	0.000	0.000	0.000	0.115
Jul
Aug
Sep
Oct
Nov
Dec
Total	2.430	0.253	0.030	0.000	2.400	0.799	0.001	0.000	0.000	0.000	0.115

Note: 1. Assume the density of soil fill is 2 ton/m³.

Assume the density of rock and broken concrete is 2.5 ton/m³.
Assume each truck of C&D wastes is 5m³.
The inert C&D materials except slurry and bentonite are disposed at Tuen Mun 38.
The slurry and bentonite are disposed at Tseung Kwun O 137.
The non-inert C&D wastes are disposed at NENT.
Assume the density of metal is 7,850 kg/m³.

Contract No. CV/2013/03 Particular Specification Appendix 1.27		Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5
Name of Department: CEDD
	Monthly Summary Waste Flow Table for 2015

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
JAN	0	0	0	0	0	33.3285	4.16	0.24	0	0	0.42
FEB	0	0	0	0	0	11.82	0.99	0	0	0	0.18
MAR	0	0	0	0	0	8.592	0	0	0	0	0.375
APRIL	0	0	0	0	0	12.81	0	0	0	0	0.04
MAY	0	0	0	0	0	16.609	0	0.154	0	0	0
JUN	0	0	0	0	0	13.676	0	0	0	0	0.015
Sub Total	0	0	0	0	0	96.8355	5.15	0.394	0	0	1.03
JUL	0	0	0	0	0	10.285	0	0	0	0	0.02
AUG	0	0	0	0	0	9.129	0	0	0	0	0.43
SEP	0	0	0	0	0	2.457	0	0	0	0	0.005
OCT	0	0	0	0	0	16.218	0	0.099	0	0	0.145
NOV	0	0	0	0	0	5.823	0	0	0	0	0.030
DEC	0	0	0	0	0	0.283	0	0	0	0	0.07
Total	0	0	0	0	0	141.03	5.15	0.493	0	0	1.73

Notes:

Contract No. CV/2013/03 Particular Specification Appendix 1.27

Name of Department: CEDD

Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5

Forecast of Total Quantities of C&D Materials to be Generated from the Contract (see Note 4)
Total Quantity Generated	Hard Rocks and Large Broken Concrete	Reused in the Contract	Reused in Other Projects	Disposed as Public Fill	Imported Fill	Metal	Paper / cardboard packaging	Plastics (see Note 3)	Chemical Waste	Others, e.g. general refuse
(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
0	0	0	0	0	350	30	4	2	1	4

Notes:

(1): The performance targets are given in PS clause 6(14) above.
(2): The waste flow table shall also include C&D materials that are specified in the Contractor to be imported for use at the Site.
(3): Plastic refer to plastic bottles/containers, plastic sheets/foam from packaging material.
(4): The Contractor shall also submit the latest forecast of the total amount of C&D materials expected to be generated from the Works, together with a breakdown of the nature

- Hard Rocks and Large Broken Concrete = Cannot be defined at this stage

-Imported Fill = Estimated by the Contractor = 1 loading = 8m 3

-Metal = Estimated by the Contractor

-Paper/cardboard packaging = Estimated by the Contractor

-Plastics = Estimated by the Contractor

- Chemical Waste = Estimated by the Contractor (Spent lubricating oil, assume density 0.9kg/L)

-Other, e.g. general refuse = Estimated by the Contractor

Contract No. CV/2013/03 Particular Specification Appendix 1.27		Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5
Name of Department: CEDD
	Monthly Summary Waste Flow Table for 2016

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
JAN	0	0	0	0	0	0.235	0	0	0	0	0.06
FEB
MAR
APRIL
MAY
JUN
Sub Total	0	0	0	0	0	0.235	0	0	0	0	0.06
JUL
AUG
SEP
OCT
NOV
DEC
Total	0	0	0	0	0	0.24	0	0	0	0	0.06

Notes:

Contract No. CV/2013/03 Particular Specification Appendix 1.27

Name of Department: CEDD

Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5

Forecast of Total Quantities of C&D Materials to be Generated from the Contract (see Note 4)
Total Quantity Generated	Hard Rocks and Large Broken Concrete	Reused in the Contract	Reused in Other Projects	Disposed as Public Fill	Imported Fill	Metal	Paper / cardboard packaging	Plastics (see Note 3)	Chemical Waste	Others, e.g. general refuse
(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
0	0	0	0	0	350	30	4	2	1	4

Notes:

(1): The performance targets are given in PS clause 6(14) above.
(2): The waste flow table shall also include C&D materials that are specified in the Contractor to be imported for use at the Site.
(3): Plastic refer to plastic bottles/containers, plastic sheets/foam from packaging material.
(4): The Contractor shall also submit the latest forecast of the total amount of C&D materials expected to be generated from the Works, together with a breakdown of the nature

- Hard Rocks and Large Broken Concrete = Cannot be defined at this stage

-Imported Fill = Estimated by the Contractor = 1 loading = 8m 3

-Metal = Estimated by the Contractor

-Paper/cardboard packaging = Estimated by the Contractor

-Plastics = Estimated by the Contractor

- Chemical Waste = Estimated by the Contractor (Spent lubricating oil, assume density 0.9kg/L)

-Other, e.g. general refuse = Estimated by the Contractor

Monthly Summary Waste Flow Table for 2015 (year)

Name of Person completing the record: KM LUI (EO) Project : Liangtang / Heung Yuen Wai Boundary Control Point Site Formation and Infrastructure Works – Contract 6 Contract No.: CV/2013/08

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics (see Note 3)	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in ‘000m3)	(in '000 kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in ‘000 m3)
Jan
Feb
Mar
Apr
May
Jun	0	0	0	0	0	0	0	0	0	0	0
Sub-total	0	0	0	0	0	0	0	0	0	0	0
Jul	0	0	0	0	0	0	0	0	0	0	0
Aug	27.831	0	5.11	0.516	22.205	0	0	0	0	0	1.783
Sep	35.826	0	1.517	1.629	32.680	0	0	0	0	0	0.434
Oct	37.112	0	0.113	5.356	31.643	0	0	0.045	0	14.08	0.185
Nov	16.853	0	0.717	2.456	13.680	4.720	0	0.102	0	18.20	0.594
Dec	51.601	0	11.077	6.827	33.697	2.529	0	0.147	0	0	0.08
Total	169.223	0	18.534	16.784	133.905	7.249	0	0.294	0	32.28	3.076

Notes: (1) The waste flow table shall also include C&D materials that are specified in the Contract to be imported for use at the Site.

(2): Plastics refer to plastic bottles/containers, plastic sheets/ foam from packaging materials.
(3): Broken concrete for recycling into aggregates.

Monthly Summary Waste Flow Table for 2016 (year)

Name of Person completing the record: KM LUI (EO) Project : Liangtang / Heung Yuen Wai Boundary Control Point Site Formation and Infrastructure Works – Contract 6 Contract No.: CV/2013/08

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics (see Note 3)	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in ‘000m3)	(in '000 kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in ‘000 m3)
Jan	58.943	0	3.811	12.131	43.001	43.109	0	0	0	0	0.695
Feb
Mar
Apr
May
Jun
Sub-total	58.943	0	3.811	12.131	43.001	43.109	0	0	0	0	0.695
Jul
Aug
Sep
Oct
Nov
Dec
Total	228.166	0	22.345	28.915	176.906	50.358	0	0.294	0	32.28	3.771

Notes: (1) The waste flow table shall also include C&D materials that are specified in the Contract to be imported for use at the Site.

(2): Plastics refer to plastic bottles/containers, plastic sheets/ foam from packaging materials.
(3): Broken concrete for recycling into aggregates.

Architectural Services Department	Form No. D/OI.03/09.002

SSC505

Contract No. / Works Order No.:

Monthly Summary Waste Flow Table for 2015 [year] [to be submitted not later than the 15^thday of each month following reporting month] (All quantities shall be rounded off to 3 decimal places.)

Month		Actual Quantities of Inert Construction Waste Generated Monthly
	(a)=(b)+(c)+(d)+(e)Total Quantity Generated	(b)Broken Concrete (see Note 4)	(c)Reused in the Contract	(d) Reused in other Projects	(e)Disposed of as Public Fill
	(in ‘000m3)	(in ‘000m3)	(in ‘000m3)	(in ‘000m3)	(in ‘000m3)
Jan	-	-	-	-	-
Feb	-	-	-	-	-
Mar	-	-	-	-	-
Apr	-	-	-	-	-
May	-	-	-	-	-
Jun	-	-	-	-	-
Sub-total	-	-	-	-	-
Jul	0	0	0	0	0
Aug	0	0	0	0	0
Sep	0.094	0	0.094	0	0
Oct	0.382	0	0.382	0	0
Nov	0.271	0	0.128	0	0.143
Dec	0.663	0	0	0	0.663
Total	1.410	0	0.604	0	0.806

Page 1 Page 2

Architectural Services Department	Form No. D/OI.03/09.002

Month					Actual Quantities of Non-inert Construction Waste Generated Monthly
	Timber		Metals		Paper/ cardboard packaging		Plastics (see Note 3)		Chemical Waste		Other Recyclable Materials _________________ (pls. specify)		General Refuse disposed of at Landfill
	(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000m3)
	generated	recycled	generated	recycled	generated	recycled	generated	recycled	generated	recycled	generated	recycled	generated
Jan	-	-	-	-	-	-	-	-	-	-	-	-	-
Feb	-	-	-	-	-	-	-	-	-	-	-	-	-
Mar	-	-	-	-	-	-	-	-	-	-	-	-	-
Apr	-	-	-	-	-	-	-	-	-	-	-	-	-
May	-	-	-	-	-	-	-	-	-	-	-	-	-
Jun	-	-	-	-	-	-	-	-	-	-	-	-	-
Sub-total	-	-	-	-	-	-	-	-	-	-	-	-	-
Jul	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00
Aug	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00
Sep	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.020
Oct	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.046
Nov	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	2.60	0.00	0.00	0.00	0.052
Dec	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.111
Total	0.00	0.00	0.00	0.00	0.00	0.00	0.00	0.00	2.60	0.00	0.00	0.00	0.229

Architectural Services Department	Form No. D/OI.03/09.002

SSC505

Contract No. / Works Order No.:

Monthly Summary Waste Flow Table for 2016 [year] [to be submitted not later than the 15^thday of each month following reporting month] (All quantities shall be rounded off to 3 decimal places.)

Month		Actual Quantities of Inert Construction Waste Generated Monthly
	(a)=(b)+(c)+(d)+(e)Total Quantity Generated	(b)Broken Concrete (see Note 4)	(c)Reused in the Contract	(d)Reused in other Projects	(e)Disposed of as Public Fill
	(in ‘000m3)	(in ‘000m3)	(in ‘000m3)	(in ‘000m3)	(in ‘000m3)
Jan	0.8	0	0	0	0.8
Feb	-	-	-	-	-
Mar	-	-	-	-	-
Apr	-	-	-	-	-
May	-	-	-	-	-
Jun	-	-	-	-	-
Sub-total	0.8	0	0	0	0.8
Jul	-	-	-	-	-
Aug	-	-	-	-	-
Sep	-	-	-	-	-
Oct	-	-	-	-	-
Nov	-	-	-	-	-
Dec	-	-	-	-	-
Total	0.8	0	0	0	0.8

Architectural Services Department	Form No. D/OI.03/09.002

Month					Actual Quantities of Non-inert Construction Waste Generated Monthly
	Timber		Metals		Paper/ cardboard packaging		Plastics (see Note 3)		Chemical Waste		Other Recyclable Materials _________________ (pls. specify)		General Refuse disposed of at Landfill
	(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000kg)		(in ‘000m3)
	generated	recycled	generated	recycled	generated	recycled	generated	recycled	generated	recycled	generated	recycled	generated
Jan	0.000	0.000	4.73	4.73	0.000	0.000	0.000	0.000	0.000	0.000	0.000	0.000	0.072
Feb	-	-	-	-	-	-	-	-	-	-	-	-	-
Mar	-	-	-	-	-	-	-	-	-	-	-	-	-
Apr	-	-	-	-	-	-	-	-	-	-	-	-	-
May	-	-	-	-	-	-	-	-	-	-	-	-	-
Jun	-	-	-	-	-	-	-	-	-	-	-	-	-
Sub-total	0.000	0.000	4.73	4.73	0.000	0.000	0.000	0.000	0.000	0.000	0.000	0.000	0.072
Jul	-	-	-	-	-	-	-	-	-	-	-	-	-
Aug	-	-	-	-	-	-	-	-	-	-	-	-	-
Sep	-	-	-	-	-	-	-	-	-	-	-	-	-
Oct	-	-	-	-	-	-	-	-	-	-	-	-	-
Nov	-	-	-	-	-	-	-	-	-	-	-	-	-
Dec	-	-			-	-	-	-	-	-	-	-	-
Total	0.000	0.000	4.73	4.73	0.000	0.000	0.000	0.000	0.000	0.000	0.000	0.000	0.072

Architectural Services Department	Form No. D/OI.03/09.002

Description of mode and details of recycling if any for the month e.g. XX kg of used timber was sent to YY site for transformation into fertilizers
4730 kg of scrap metal was sent to Yat Fung for transformation for reuse	0	0	0	0	0

Notes:	(1)	The performance targets are given in the Particular Specification on Environmental Management Plan.
	(2)	The waste flow table shall also include construction waste that are specified in the Contract to be imported for use at the site.
	(3)	Plastics refer to plastic bottles/containers, plastic sheets/foam from packaging material.
	(4) (5)	Broken concrete for recycling into aggregates. If necessary, use the conversion factor: 1 full load of dumping truck being equivalent to 6.5 m3 by volume.
