Appendix I - Monthly Summary Waste Flow Table for 2015

(All quantities shall be rounded off to 3 decimal places)

Month	Actual Quantities of Inert C&D Materials Generated / Imported (in '000 m3)							Actual Quantities of Other C&D Materials / Wastes Generated
	Total Quantities Generated [a+b+c+d)	Broken Concrete (including rock for recycling into aggregates) (a)	Reused in the Contract (b)	Reused in Other Projects (c)	Disposed as Public Fill (d)	Imported C&D Material	Metal (in '000kg)	Paper/ Cardboard Packaging (in '000kg)	Plastic (bottles/containers, plastic sheets/ foams from package material) (in '000kg)	Chemical Waste (in '000kg)	Others (e.g. General Refuse etc.) (in '000m3)
January	66.2666	0.0000	0.0670	65.6529	0.5467	0.1150	0.0000	0.2500	0.0000	0.0000	0.0617
February	57.9980	0.0000	0.0000	57.3858	0.6121	0.3505	3.3200	0.3900	0.0000	0.5280	0.0908
March	66.0198	0.0000	0.3614	65.3359	0.3225	0.0729	0.0000	0.2920	0.0000	0.7040	0.1293
April	49.2562	0.0000	0.2770	48.7725	0.2066	0.1928	0.0000	0.2300	0.0000	0.0000	0.2423
May	41.7957	0.0000	8.7663	32.6095	0.4199	0.8683	0.0000	0.1300	0.0000	2.6400	0.0511
June	32.4389	0.0000	5.2132	26.7733	0.4524	0.9260	0.0000	0.5400	0.0000	0.5280	0.1703
Half-year total	313.7751	0.0000	14.6850	296.5299	2.5602	2.5255	3.3200	1.8320	0.0000	4.4000	0.7454
July	28.0854	0.0000	0.5171	26.7761	0.7922	1.0930	0.0000	0.6600	0.0000	0.8800	0.0496
August	47.6646	0.0000	0.4526	46.9470	0.2650	0.3577	0.0000	0.4500	0.6000	1.9360	0.1021
September	39.4931	0.0000	0.1339	38.4616	0.8975	0.3062	0.0000	0.0000	0.0000	1.0560	0.0611
October	45.0442	0.0000	1.6666	43.0977	0.2800	0.0680	0.0000	0.5800	0.9000	2.9920	0.0716
November	46.3947	0.0000	2.5152	42.1530	1.7265	0.0444	0.0000	0.0000	0.0000	3.1680	0.0953
December	0.0000
Yearly Total	520.4571	0.0000	19.9704	493.9653	6.5214	4.3948	3.3200	3.5220	1.5000	14.4320	1.1251

(All quantities shall be rounded off to 3 decimal places)

Year	Actual Quantities of Inert C&D Materials Generated / Imported (in '000 m3)							Actual Quantities of Other C&D Materials / Wastes Generated
	Total Quantities Generated [a+b+c+d)	Broken Concrete (including rock for recycling into aggregates) (a)	Reused in the Contract (b)	Reused in Other Projects (c)	Disposed as Public Fill (d)	Imported C&D Material	Metal (in '000kg)	Paper/ Cardboard Packaging (in '000kg)	Plastic (bottles/containers, plastic sheets/ foams from package material) (in '000kg)	Chemical Waste (in '000kg)	Others (e.g. General Refuse etc.) (in '000m3)
2013	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000
2014	425.4406	0.0000	2.7362	376.3945	46.3099	5.6245	3.2100	0.4390	0.0070	10.8800	2.2609
2015	520.4571	0.0000	19.9704	493.9653	6.5214	4.3948	3.3200	3.5220	1.5000	14.4320	1.1251
2016
2017
2018
Total	945.8977	0.0000	22.7066	870.3598	52.8312	10.0193	6.5300	3.9610	1.5070	25.3120	3.3859

Remark:
	1) Density of C&D material to be	2.2	metric ton/m3	3) Density of Spent Oil to be	0.88	metric ton/m3
	2) Density of General Refuse to be	1.6	metric ton/m3

Name of Department: CEDD Contract No.: CV/2012/09

Monthly Summary Waste Flow Table for 2015 (year)

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in m3)	(in '000m3)
Jan	3.864	0.105	0.648	0.000	3.216	0.118	0.000	0.000	0.000	0.040	0.080
Feb	2.429	0.049	1.518	0.000	0.911	0.100	0.000	0.000	0.003	0.900	0.070
Mar	3.713	0.029	0.270	0.000	3.443	0.100	0.000	0.000	0.006	0.000	0.080
Apr	3.597	0.115	2.308	0.000	1.289	0.090	0.003	0.000	0.000	0.000	0.065
May	1.357	0.197	0.108	0.000	1.249	0.100	0.000	0.000	0.012	0.000	0.065
Jun	2.515	0.053	0.840	0.000	1.675	0.125	0.000	0.000	0.030	0.800	0.060
Sub-total	17.475	0.547	5.692	0.000	11.783	0.633	0.003	0.000	0.051	1.740	0.420
Jul	1.177	0.030	0.351	0.000	0.826	1.564	0.000	0.000	0.000	0.000	0.065
Aug	1.966	0.164	0.294	0.000	1.672	0.956	0.002	0.000	0.001	0.000	0.130
Sep	2.092	0.027	0.264	0.000	1.828	1.141	0.000	0.000	0.001	0.000	0.115
Oct	2.462	0.381	1.500	0.000	0.962	0.226	0.000	0.000	0.001	0.000	0.125
Nov	2.990	0.709	1.200	0.000	1.790	0.066	0.001	0.000	0.000	0.000	0.130
Dec
Total	28.162	1.859	9.301	0.000	18.861	4.586	0.006	0.000	0.054	1.740	0.985

Note: 1. Assume the density of soil fill is 2 ton/m³ .

1. Assume the density of rock and broken concrete is 2.5 ton/m³ .
2. Assume each truck of C&D wastes is 5m³ .
3. The inert C&D materials except slurry and bentonite are disposed at Tuen Mun 38.
4. The slurry and bentonite are disposed at Tseung Kwun O 137.
5. The non-inert C&D wastes are disposed at NENT.
6. Assume the density of metal is 7,850 kg/m³ .

Contract No. CV/2013/03 Particular Specification Appendix 1.27		Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5
Name of Department: CEDD
	Monthly Summary Waste Flow Table for 2015

Month	Actual Quantities of Inert C&D Materials Generated Monthly							Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill		Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)		(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
JAN	0	0	0	0	0		33.3285	4.16	0.24	0	0	0.42
FEB	0	0	0	0	0		11.82	0.99	0	0	0	0.18
MAR	0	0	0	0	0		8.592	0	0	0	0	0.375
APRIL	0	0	0	0	0		12.81	0	0	0	0	0.04
MAY	0	0	0	0	0		16.609	0	0.154	0	0	0
JUN	0	0	0	0	0		13.676	0	0	0	0	0.015
Sub Total	0	0	0	0	0		96.8355	5.15	0.394	0	0	1.03
JUL	0	0	0	0	0		10.285	0	0	0	0	0.02
AUG	0	0	0	0	0		9.129	0	0	0	0	0.43
SEP	0	0	0	0	0		2.457	0	0	0	0	0.005
OCT	0	0	0	0	0		16.218	0	0.099	0	0	0.145
NOV	0	0	0	0	0		5.823	0	0	0	0	0.030
DEC
Total	0	0	0	0	0		140.75	5.15	0.493	0	0	1.66

Notes:

Contract No. CV/2013/03 Particular Specification Appendix 1.27

Name of Department: CEDD

Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5

Forecast of Total Quantities of C&D Materials to be Generated from the Contract (see Note 4)
Total Quantity Generated	Hard Rocks and Large Broken Concrete	Reused in the Contract	Reused in Other Projects	Disposed as Public Fill	Imported Fill	Metal	Paper / cardboard packaging	Plastics (see Note 3)	Chemical Waste	Others, e.g. general refuse
(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
0	0	0	0	0	350	30	4	2	1	4

Notes:

(1)

The performance targets are given in PS clause 6(14) above.

(2)

The waste flow table shall also include C&D materials that are specified in the Contractor to be imported for use at the Site.

(3)

Plastic refer to plastic bottles/containers, plastic sheets/foam from packaging material.

(4)

The Contractor shall also submit the latest forecast of the total amount of C&D materials expected to be generated from the Works, together with a breakdown of the nature

- Hard Rocks and Large Broken Concrete = Cannot be defined at this stage

-Imported Fill = Estimated by the Contractor = 1 loading = 8m 3

-Metal = Estimated by the Contractor

-Paper/cardboard packaging = Estimated by the Contractor

-Plastics = Estimated by the Contractor

- Chemical Waste = Estimated by the Contractor (Spent lubricating oil, assume density 0.9kg/L)

-Other, e.g. general refuse = Estimated by the Contractor
