Appendix I - Monthly Summary Waste Flow Table for 2016

(All quantities shall be rounded off to 3 decimal places)

Month	Actual Quantities of Inert C&D Materials Generated / Imported (in '000 m3)							Actual Quantities of Other C&D Materials / Wastes Generated
	Total Quantities Generated [a+b+c+d)	Broken Concrete (including rock for recycling into aggregates) (a)	Reused in the Contract (b)	Reused in Other Projects (c)	Disposed as Public Fill (d)	Imported C&D Material	Metal (in '000kg)	Paper/ Cardboard Packaging (in '000kg)	Plastic (bottles/containers, plastic sheets/ foams from package material) (in '000kg)	Chemical Waste (in '000kg)	Others (e.g. General Refuse etc.) (in '000m3)
January	72.2029	0.0000	0.6482	31.8061	39.7486	0.7684	26.2000	0.0000	0.0000	1.2320	0.1247
February	55.6715	0.0000	1.0145	38.3484	16.3085	0.9343	8.3800	0.9800	0.0000	1.4080	0.1089
March	34.1616	0.0000	0.3100	29.3514	4.5003	0.9272	0.0000	0.0000	0.0000	11.7920	0.0682
April	0.0000
May	0.0000
June	0.0000
Half-year total	162.0360	0.0000	1.9727	99.5059	60.5574	2.6299	34.5800	0.9800	0.0000	14.4320	0.3018
July	0.0000
August	0.0000
September	0.0000
October	0.0000
November	0.0000
December	0.0000
Yearly Total	162.0360	0.0000	1.9727	99.5059	60.5574	2.6299	34.5800	0.9800	0.0000	14.4320	0.3018

(All quantities shall be rounded off to 3 decimal places)

Year	Actual Quantities of Inert C&D Materials Generated / Imported (in '000 m3)							Actual Quantities of Other C&D Materials / Wastes Generated
	Total Quantities Generated [a+b+c+d)	Broken Concrete (including rock for recycling into aggregates) (a)	Reused in the Contract (b)	Reused in Other Projects (c)	Disposed as Public Fill (d)	Imported C&D Material	Metal (in '000kg)	Paper/ Cardboard Packaging (in '000kg)	Plastic (bottles/containers, plastic sheets/ foams from package material) (in '000kg)	Chemical Waste (in '000kg)	Others (e.g. General Refuse etc.) (in '000m3)
2013	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000	0.0000
2014	425.4406	0.0000	2.7362	376.3945	46.3099	5.6245	3.2100	0.4390	0.0070	10.8800	2.2609
2015	570.9459	0.0000	20.8159	543.2162	6.9138	4.5492	14.1300	3.9220	1.5000	16.1920	1.1696
2016	162.0360	0.0000	1.9727	99.5059	60.5574	2.6299	34.5800	0.9800	0.0000	14.4320	0.3018
2017
2018
Total	1158.4225	0.0000	25.5248	1019.1167	113.7810	12.8036	51.9200	5.3410	1.5070	41.5040	3.7323

Remark:
	1) Density of C&D material to be	2.2	metric ton/m3	3) Density of Spent Oil to be	0.88	metric ton/m3
	2) Density of General Refuse to be	1.6	metric ton/m3

Name of Department: CEDD Contract No.: CV/2012/09

Monthly Summary Waste Flow Table for 2016 (year)

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in m3)	(in '000m3)
Jan	2.430	0.253	0.030	0.000	2.400	0.799	0.001	0.000	0.000	0.000	0.115
Feb	1.225	0.651	0.020	0.000	1.205	1.141	0.000	0.000	0.000	0.000	0.110
Mar	1.084	0.417	0.000	0.000	1.084	0.831	0.000	0.000	0.001	0.000	0.090
Apr
May
Jun
Sub-total	4.739	1.321	0.050	0.000	4.689	2.772	0.001	0.000	0.001	0.000	0.315
Jul
Aug
Sep
Oct
Nov
Dec
Total	4.739	1.321	0.050	0.000	4.689	2.772	0.001	0.000	0.001	0.000	0.315

Note: 1. Assume the density of soil fill is 2 ton/m³ .

1. Assume the density of rock and broken concrete is 2.5 ton/m³ .
2. Assume each truck of C&D wastes is 5m³ .
3. The inert C&D materials except slurry and bentonite are disposed at Tuen Mun 38.
4. The slurry and bentonite are disposed at Tseung Kwun O 137.
5. The non-inert C&D wastes are disposed at NENT.
6. Assume the density of metal is 7,850 kg/m³ .

Contract No. CV/2013/03 Particular Specification Appendix 1.27		Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5
Name of Department: CEDD
	Monthly Summary Waste Flow Table for 2016

Month	Actual Quantities of Inert C&D Materials Generated Monthly						Actual Quantities of C&D Wastes Generated Monthly
	Total Quantity Generated	Hard Rock and Large Broken Concrete	Reused in the Contract	Reused in other Projects	Disposed as Public Fill	Imported Fill	Metals	Paper/ cardboard packaging	Plastics	Chemical Waste	Others, e.g. general refuse
	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
JAN	0	0	0	0	0	0.235	0	0	0	0	0.06
FEB	0	0	0	0	0	0.141	0	0	0	0	0.045
MAR	0	0	0	0	0	0.1785	0	0	0	0	0.055
APRIL
MAY
JUN
Sub Total	0	0	0	0	0	0.5545	0	0	0	0	0.16
JUL
AUG
SEP
OCT
NOV
DEC
Total	0	0	0	0	0	0.55	0	0	0	0	0.16

Notes:

Contract No. CV/2013/03 Particular Specification Appendix 1.27

Name of Department: CEDD

Liantang/Heung Yuen Wai Boundary Control Point Site Formation and infrastructure Works Contract 5

Forecast of Total Quantities of C&D Materials to be Generated from the Contract (see Note 4)
Total Quantity Generated	Hard Rocks and Large Broken Concrete	Reused in the Contract	Reused in Other Projects	Disposed as Public Fill	Imported Fill	Metal	Paper / cardboard packaging	Plastics (see Note 3)	Chemical Waste	Others, e.g. general refuse
(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000m3)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000kg)	(in '000m3)
0	0	0	0	0	350	30	4	2	1	4

Notes:

(1)

The performance targets are given in PS clause 6(14) above.

(2)

The waste flow table shall also include C&D materials that are specified in the Contractor to be imported for use at the Site.

(3)

Plastic refer to plastic bottles/containers, plastic sheets/foam from packaging material.

(4)

The Contractor shall also submit the latest forecast of the total amount of C&D materials expected to be generated from the Works, together with a breakdown of the nature

- Hard Rocks and Large Broken Concrete = Cannot be defined at this stage

-Imported Fill = Estimated by the Contractor = 1 loading = 8m 3

-Metal = Estimated by the Contractor

-Paper/cardboard packaging = Estimated by the Contractor

-Plastics = Estimated by the Contractor

- Chemical Waste = Estimated by the Contractor (Spent lubricating oil, assume density 0.9kg/L)

-Other, e.g. general refuse = Estimated by the Contractor
